Whirlpool WP8571920 Electronic Control Board (User Interface Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP8571920 replaces AP6013403, 8571920, 4438676, PS11746629.

Description

This electronic control board is the user interface assembly that controls dryer cycles, settings and display functions, restoring responsive button/touchpad control and cycle selection. What it does:

• Manages dryer control logic and timer functions so cycles start, stop and advance correctly
• Processes user input from the touchpad/buttons and updates the display/status lights
• Communicates with other dryer modules to run selected cycles and heating commands
• Commonly replaced when controls are unresponsive, display is blank/erratic, or cycles won't start

What's included:

• One electronic control board / user interface assembly

Install notes:

• Disconnect power to the dryer before servicing to avoid shock hazard
• Handle the board carefully and avoid static discharge; use grounding or an anti-static wrist strap if available
• Some disassembly (top/front/control panel removal) is required; follow the dryer's service manual for detailed steps
• Test function after reconnection before fully reassembling the cabinet
