Whirlpool W11518204 User Interface Assembly (Touch Control), Black OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11518204 replaces AP7013885, W10905593, W11163771, W11169239, W11214887, W11456119.

Description

Restore reliable, responsive controls with this user interface assembly. It reads your touch/button inputs and communicates them to the main control so you can select settings, start/stop cycles, and see status feedback as intended. What it does:

• Registers touch/button inputs and sends commands to the main control
• Provides status indication through UI LEDs/indicators
• Helps address unresponsive or intermittent controls and dark/no-display conditions
• Replaces cracked, moisture-damaged, or non-responsive UI modules

What's included:

• One user interface assembly

Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Handle the board as ESD-sensitive; avoid touching connector pins and circuitry
• Transfer any reusable brackets/trim from the original part as needed; seat all ribbon cables and connectors fully
• Route harnesses carefully and verify connector orientation before restoring power
