Whirlpool WPW10298120 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10298120 replaces AP6019034, 4444398, PS11752338, W10116134, W10298120.

Description

This electronic control board interprets control-panel inputs and manages the display/indicators so the appliance runs as designed. Replacing a failed board restores responsive controls and accurate status feedback when the panel is dead or erratic.

• Receives button/touch inputs and relays commands to the appliance's control system
• Drives the display, LEDs, and status indicators
• Enables selection of operating modes, cycles, and temperature/time where applicable
• Common symptoms include unresponsive controls, blank or flickering display, random beeping or error codes, or inability to start/change settings

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker before servicing; verify no power is present
• Use ESD protection and handle the board by its edges
• Photograph wiring and move each connector to the matching position on the new board
• Reuse mounting hardware/trim; perform any required setup, calibration, or diagnostics per the tech sheet
