Whirlpool W10300198 Burner Valve (Surface Gas Control), Single OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10300198 replaces AP5272896, 2117206, AH3500334, EA3500334, PS3500334.

Description

This surface burner valve controls gas flow to a single cooktop burner so the burner lights and adjusts heat reliably. It replaces a worn or failed valve to restore proper fuel delivery and burner operation. What it does:

• Regulates gas flow to the burner so flame size matches the control knob setting
• Stops or reduces gas to the burner when set to off, helping prevent unwanted flow
• Commonly used when a burner won't light, won't stay lit, or won't produce heat at expected settings
• Works as the in-line control between the manifold and the individual burner

What's included: One burner valve (single) Install notes:

• Turn off the gas supply and disconnect power to the appliance before starting work
• Use proper fittings and tighten connections to manufacturer torque; check all joints for leaks after installation
