Whirlpool W10850894 Burner Valve (Gas Range) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10850894 replaces AP6035956.

Description

This burner valve controls gas flow to a single cooktop burner so you can adjust and maintain the flame for cooking. Replaces a worn or leaky valve to restore safe, steady burner operation. What it does:

• Regulates gas flow to one cooktop burner so flame size responds to the control knob
• Helps stop unwanted gas flow when the valve is closed
• Commonly replaced for leaks, a burner that won't light, or inconsistent flame size
• Works as the control point between the manifold and the burner orifice

What's included: One burner valve. Install notes:

• Turn off gas supply and unplug the appliance before any service
• This part mounts between the manifold and burner; some disassembly of the cooktop or control panel may be required
• Inspect fittings and gaskets for proper sealing during reassembly; do not reuse damaged seals
