Whirlpool W11670030 Wire Harness (Evaporator) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11670030 replaces AP7213060, W11324678.

Description

This evaporator wire harness routes power and signals to the freezer evaporator components so the cooling and defrost systems operate correctly. It replaces a damaged or disconnected harness to restore circuit connections behind the evaporator. What it does:

• Provides electrical connections to evaporator components such as the defrost heater, thermostat/thermistor, and fan motor
• Ensures consistent signaling for defrost cycles and evaporator fan operation
• Helps stop symptoms like a warm freezer, intermittent cooling, or failed defrost when caused by wiring faults
• Maintains proper routing and secure connector fit to prevent shorts or intermittent contacts

What's included:

• One evaporator wire harness assembly

Install notes:

• Disconnect power to the appliance before starting any repair
• Remove evaporator cover panels carefully; avoid bending evaporator fins
• Match connector shapes and routing to the original harness; secure away from moving parts
