Whirlpool W11625681 Wire Assembly (Xl Double-Insulated) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11625681 replaces AP7194993, W11430967, W10410814, WPW10410814.

Description

This wire assembly routes power and control signals within the appliance using XL double-insulated conductors to protect circuits and reduce wear. It replaces damaged or brittle internal wiring to restore reliable electrical connections. What it does:

• Replaces an internal wire harness used for power and signal routing
• Double-insulated conductors help prevent shorting and reduce chafing risk
• Commonly used when wiring shows burn, breaks, or loss of continuity
• Helps stop intermittent operation caused by damaged internal wires

What's included:

• One wire assembly

Install notes:

• Disconnect power before inspecting or replacing wiring to avoid shock
• Secure wiring away from sharp edges and moving parts to prevent damage
