Whirlpool W11446236 Wire Electrode (Broil Ignitor), Yellow OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11446236 replaces AP6986470, W11311196.

Description

This yellow wire electrode connects the broil ignitor to the oven's ignition system so the broil burner can spark and light reliably. Replaces a damaged or brittle ignitor lead to restore consistent broil operation. What it does:

• Transfers ignition spark/current from the control to the broil ignitor so the broil burner can light
• Commonly used when broil fails to ignite, sparks are intermittent, or wire insulation is cracked or burned
• Serves as the low-voltage lead between the oven control/igniter and the broil element/ignitor assembly

What's included:

• One yellow wire electrode (single lead) as pictured

Install notes:

• Disconnect power (and gas supply where applicable) before inspecting or replacing any ignition components
• Handle the electrode tip and connector carefully to avoid damage to the ceramic/insulator
• Route and secure the wire away from hot surfaces and moving parts; replace any damaged clips or insulation
