Parts for Gaggenau CK590-615: 01 - Complete Parts

A replacement coil tension spring that restores proper tension and smooth movement to the appliance component it attaches to, helping return doors, levers, or assemblies to their intended position for reliable operation. What it does:

• Provides tension and return force for a door, lever, or linkage to ensure proper closing and positioning
• Helps eliminate sagging, sticking, or uneven movement caused by a worn or broken spring
• Can reduce rattling or noise from loose components when the spring is worn
• Restores normal mechanical action so other parts operate under correct load

• Disconnect power and water before servicing the appliance
• Use appropriate tools and caution—springs can be under tension and may release suddenly
• Compare the new spring to the original to ensure correct length and end configuration before installation
• If the appliance uses matching springs on both sides, replace both to maintain balanced operation

This replacement hotplate is the cooktop surface element that provides direct heat for pots and pans on electric ranges. It restores a damaged, cracked, or non-heating burner so you can cook safely and consistently. What it does

• Heats cookware directly as the primary cooking surface on electric ranges
• Replaces a cracked, visibly damaged, or non-functioning surface element
• Restores consistent heat delivery when the original burner fails to warm
• Works with the range's existing control and wiring when installed correctly

• Disconnect power to the range at the breaker before servicing to avoid shock
• Remove the cooktop or access panel per your model's service instructions to access the element
• Handle the element carefully to avoid bending terminals or damaging the mounting surfaces

This insulator protects and isolates a wire terminal connection on the appliance, preventing shorts and stabilizing the terminal for reliable electrical contact. It's a direct-fit replacement used where the terminal mates to the wiring harness. What it does:

• Insulates and shields a wire terminal to prevent accidental shorts
• Helps stabilize and position the terminal for consistent electrical contact
• Used when a cracked, melted, or missing insulator causes loose or exposed connections
• Compatible with terminal blocks and connector housings where the OEM insulator is specified

• Disconnect power at the breaker or appliance plug before servicing electrical components.
• Replace only the failed insulator; inspect adjacent terminals and wiring for heat or damage.
• Push the insulator into place over the terminal until it seats firmly; ensure the wire is fully inserted and secured.
• If wiring, terminals, or connector housing show melting or corrosion, replace those parts as well.

This strain relief secures the cooktop power cord where it enters the appliance, protecting wiring from pull damage and reducing stress on the terminal connection for safer, more reliable operation. Ideal when the cord area shows wear or looseness. What it does:

• Holds the power cord firmly at the cooktop entry to prevent tugging on internal wiring
• Reduces risk of frayed wires, loose terminals, and intermittent power caused by cord movement
• Helps maintain a stable electrical connection at the terminal block
• Commonly replaced when the cord jacket is damaged or the cord pulls freely at the entry point

• One strain relief as shown

• Disconnect electrical power at the breaker before any service; confirm power is off with a multimeter
• Access typically requires removing the cooktop/back panel to reach the terminal area
• Secure the cord under the strain relief and tighten fasteners per OEM orientation; avoid overtightening

This glass scraper is a handheld tool designed to remove stubborn, baked-on residue from smooth cooktop glass and ceramic surfaces, helping restore a clean cooking surface without harsh scouring. What it does:

• Scrapes away burnt-on food, dried spills and adhesive residue that regular cleaning can't remove
• Helps maintain an even, smooth glass-ceramic cooktop surface for better cleaning and appearance
• Useful for spot-cleaning without abrasive pads that can scratch finishes
• Works as a prep tool before routine cleaning to speed up maintenance

• Use only on cool, unheated cooktop surfaces to avoid damage and injury
• Hold the scraper at a low angle and use light, controlled strokes; avoid excessive force
• Replace blades or blade inserts as needed — handle blades carefully and dispose of used blades safely
• Keep out of reach of children and store with blade covered or retracted when not in use
