Parts for Maytag MGR6775BDB18: 02 - Control Panel Parts

Note: Left hand side

Note: Right hand side.

Color: Black. For biscuit order 98008169. For white order WP98008544.

This electronic control board manages the appliance's cycle selection, timing and user interface so the unit runs the programmed functions reliably. It replaces a failed control to restore responsive buttons, accurate cycles and display feedback. What it does:

• Regulates cycle selection, timing and start/stop commands for normal operation
• Communicates with sensors and components to control heating, motor and valve functions
• Replaces a faulty control that causes blank display, unresponsive controls or incorrect cycle behavior
• Helps correct intermittent power or error-code conditions tied to a failed control board

• Disconnect power to the appliance before any service to avoid shock or damage
• Handle the board by its edges and avoid touching circuitry; use anti-static precautions if available
• Verify wiring harness connections match the replacement before securing the new board

A shoulder screw that secures appliance components and provides a precise pivot or spacer point. Replaces a missing or worn screw to restore alignment, reduce rattling, and keep panels and assemblies securely in place. What it does:

• Provides a fixed-diameter shoulder for pivots, spacers, or mounting points in assemblies.
• Holds panels and moving components at the correct distance to prevent binding or friction.
• A missing or worn shoulder screw can cause misalignment, rattling, or loose parts during operation.
• Used where a smooth-bearing surface and controlled clearance are required between parts.

• Disconnect power to the appliance (unplug or shut off breaker) before servicing.
• Handle small fasteners carefully to avoid dropping into assemblies; magnetic pickup tools can help.
• Start threads by hand to avoid cross-threading; tighten snugly but avoid overtightening.

A shoulder screw that secures appliance components and provides a precise pivot or spacer point. Replaces a missing or worn screw to restore alignment, reduce rattling, and keep panels and assemblies securely in place. What it does:

• Provides a fixed-diameter shoulder for pivots, spacers, or mounting points in assemblies.
• Holds panels and moving components at the correct distance to prevent binding or friction.
• A missing or worn shoulder screw can cause misalignment, rattling, or loose parts during operation.
• Used where a smooth-bearing surface and controlled clearance are required between parts.

• Disconnect power to the appliance (unplug or shut off breaker) before servicing.
• Handle small fasteners carefully to avoid dropping into assemblies; magnetic pickup tools can help.
• Start threads by hand to avoid cross-threading; tighten snugly but avoid overtightening.
