Parts for Thermador MTR-36: 03 - Power Section Parts

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

This replacement mounting bracket secures appliance components to their frames, restoring proper alignment and preventing movement. It's a simple, durable part that helps stop rattling and keeps assemblies stable during operation. What it does:

• Secures and supports internal components or subassemblies to the appliance frame
• Prevents parts from shifting, vibrating, or rubbing during use
• Helps restore proper alignment for smooth operation
• Common symptom: loose, rattling, or misaligned components near the bracket location

• Bracket only

• Turn off power to the appliance and disconnect power before starting work
• Inspect adjacent fasteners and mounting points; replace any damaged hardware
• Use manufacturer-recommended screws and torque; avoid over-tightening

This diode is a small rectifier used on the appliance control electronics to allow current to flow in one direction, protecting the board and enabling proper control signals. Replacing a failed diode restores correct circuit behavior. What it does:

• Provides one-way current flow on the control board to prevent reverse voltage
• Protects sensitive electronics from backfeed and voltage spikes
• Can prevent control errors caused by a shorted or open diode
• Commonly replaced when control circuits fail to power or behave intermittently

• Disconnect power to the appliance before accessing controls to avoid shock
• Handle circuit boards and components with ESD care; avoid touching traces and contacts

This replacement capacitor with internal resistor helps stabilize control circuits and assist motor start in compatible appliances, restoring reliable electrical performance and preventing intermittent operation. What it does

• Provides the capacitance needed for motor start/run and helps suppress electrical noise in control circuits.
• Supports steady voltage during startup to reduce motor humming or failure to start.
• Can resolve intermittent operation, erratic control behavior, or startup delays when failing.
• Contains an internal bleed/resistor to safely discharge stored energy and reduce residual charge risk.

• Disconnect power at the breaker and unplug the appliance before accessing electrical components.
• Capacitors can hold a charge — discharge safely and use insulated tools.
• Handle carefully to avoid damage from bending leads or crushing the housing.

This 3/8 in. cable clamp secures wiring and small hoses to the appliance chassis to prevent chafing and keep connections tidy. It's a simple replacement that restores proper routing and strain relief. What it does:

• Holds a single cable or small hose in place to reduce movement and wear
• Prevents wiring from rubbing against sharp edges or vibrating loose
• Helps maintain safe, organized internal routing for better reliability
• Commonly used where a compact clamp is needed for 3/8 in. diameter cables

• One 3/8 in. cable clamp

• Inspect surrounding wiring and routing before installing; replace any damaged wires or insulation
• Install in the same location and orientation as the original; secure firmly but avoid over-tightening
• Disconnect power to the appliance before servicing to reduce shock risk
• Use basic hand tools; no special tools required for most installations

This thermal fuse stops excessive heat build-up by opening the circuit when temperatures get unsafe, protecting the appliance and its heating components. Replace a failed fuse to restore normal heating and safety functions. What it does

• Opens the circuit if overheating is detected to prevent damage or fire risk.
• Prevents the heating element or motor from running when the fuse is blown.
• Common symptom: appliance fails to heat or runs but produces no heat.
• Common symptom: appliance does not start or suddenly stops during a heat cycle.

• One thermal fuse.

• Disconnect power to the appliance before servicing to avoid shock or injury.
• Replace with the exact OEM part number; improper substitutes may cause malfunction or safety issues.
• Inspect surrounding wiring and heating components for faults that could cause repeated fuse failures.

This metal capacitor mounting plate secures the appliance capacitor to the chassis, helping keep the capacitor stable and properly positioned for reliable electrical connections. Fits OEM replacement needs where the original mounting plate is damaged or missing. What it does:

• Provides a secure attachment point for the start/run capacitor to prevent movement or contact with other components
• Helps maintain correct capacitor orientation for reliable electrical connections
• Reduces vibration and rattling that can lead to wire chafing or connector stress
• Supports safe, stable capacitor placement after repair or replacement

• Always disconnect power to the appliance before starting work
• Discharge or isolate the capacitor per manufacturer instructions before handling nearby parts
• Use appropriate hand tools to remove fasteners and secure the plate to the chassis
• Verify proper clearance from moving parts and tight, non-corroded fasteners after installation
