Parts for Gaggenau ED220-600: 04 - Door Parts

This inner door panel provides the dishwasher's interior door surface and restores a solid mounting surface for controls and insulation. It replaces cracked or damaged inner door shells to help stop drafts and improve door stability. What it does:

• Forms the inner shell of the dishwasher door and supports internal components
• Replaces cracked, warped, or punctured inner panels that can allow insulation loss
• Helps restore proper door alignment and reduce rattling or loose-feeling doors
• Can stop minor leak paths when the outer seal and fasteners are correctly reinstalled

• One inner door panel only

• Disconnect power and water to the appliance before starting; support the door to prevent dropping
• Remove door trim, handle, and inner fasteners to swap panels; keep track of screws and clips
• Reattach any wiring harnesses or insulation exactly as removed; test door operation before normal use
• Wear gloves to avoid cuts from sharp sheet edges and follow manufacturer instructions for torque and fastener placement

This outer door glass is the exterior replacement panel for compatible Bosch ovens and ranges, restoring the door's appearance and helping retain heat. Designed to match the oven's black finish for a factory look. What it does

• Replaces cracked, chipped, or scratched outer door glass to restore appearance.
• Helps maintain proper heat retention and visibility through the oven door when intact.
• Reduces drafts and heat loss caused by damaged or missing exterior glass.
• Restores a secure mounting surface for the inner door assembly and trim.

• One outer door glass (black). Only the outer glass panel is included.

• Disconnect power to the appliance and allow the oven to cool completely before starting.
• Handle glass with care—wear cut-resistant gloves and eye protection to avoid injury.
• Follow the manufacturer's disassembly sequence (hinges/trim removal may be required); avoid forcing components.

This right-side outer door trim replaces the damaged or worn exterior panel on compatible Bosch dishwashers, restoring the door's appearance and helping keep underlying components protected from moisture. It's a direct-fit trim piece for the right door edge. What it does:

• Covers and protects the right edge of the dishwasher door against chips, scratches, and moisture.
• Restores the door's finished appearance when the original trim is cracked, dented, or missing.
• Helps maintain a consistent seal and alignment along the door edge when installed correctly.
• Prevents dirt and debris from entering the door cavity and interfering with internal components.

• One right-side outer door trim panel.

• Intended for replacement by a technician or experienced DIYer familiar with appliance disassembly.
• Power off and disconnect the appliance from its electrical supply before service.
• Take care removing the inner door panel and any attached hardware to avoid damaging clips or wiring; save fasteners for reassembly.

This touch pad is the user interface membrane that sends button commands to the dishwasher's control board, restoring responsive touch-button operation and accurate cycle selection. Designed to match the OEM shape and connector. What it does:

• Replaces worn or damaged touch-sensitive buttons so the dishwasher accepts user inputs reliably.
• Fixes symptoms such as unresponsive or intermittent buttons, stuck or incorrect cycle selections, and missing button feedback.
• Restores normal control-panel operation without replacing the entire console assembly.
• Works with the original control board using the factory connector and mounting points.

• Disconnect power to the appliance before starting any repair to avoid shock or damage.
• Removal of the front console or door inner panel may be required; retain all screws and fasteners.
• Handle the membrane carefully to avoid creasing or contaminating contact surfaces.
• Test the control board and wiring harness for faults.
