Parts for Maytag CSG9900AAE: 04 - Top Assembly Parts

This control switch is the user-facing rotary selector that lets the appliance select cycles and settings. It restores clear, tactile control so the unit responds correctly when you turn the knob. What it does:

• Selects operating cycles and settings when the knob is turned
• Routes electrical signals from the control panel to the selected function
• Commonly replaced when settings do not change or the control feels loose/slips
• Resolves intermittent or unresponsive cycle selection and erratic behavior

• Disconnect power before attempting any repair to avoid electrical shock
• Accessible from the control panel; remove trim or console as needed per your model's service instructions
• Test function after reassembly; do not force the selector or use excessive torque

Color: Black.

This genuine OEM part is a cooktop grill burner. The grill burner is the component part that allows the gas flame to spark so that the stove can perform its job of cooking and heating. If the stove burners are no longer producing a flame or not turning on at all, it might be time to replace the grill burner. Luckily this is a relatively simple repair.To start, make sure that all power to the stove has been turned off by either unplugging the appliance or shutting off the circuit breaker. Close the shut off valve on the propane gas tank. Remove the cooking grate and the flame tamer from the top of the damaged burner. Pull the cotter pin out of the back of the burner. Remove the burner mounting screws. Pull the burner back then up to remove it from the manifold and remove the burner. Place the new burner into the manifold and fasten the mounting screws. Reinstall the cotter pin and flame tamer and restore the gas and power back to the appliance.This replacement part is sold individually and is compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Sears/Kenmore brand stoves.

A small lock-style nut that secures a threaded shaft or fastener to prevent loosening from vibration and normal use. Restores a firm connection so the appliance parts stay aligned and operate quietly and reliably. What it does:

• Locks a threaded connection in place to prevent backing off from vibration
• Keeps rotating or mounted components secured to reduce wobble or movement
• Helps stop noises caused by loose fasteners or shifting parts
• Restores proper fit where a worn or missing nut allowed play

• Disconnect power (and water if applicable) before starting any repair
• Use the correct size wrench/socket and hold mating hardware to avoid twisting other components
• Inspect threads for damage; replace mating fasteners if stripped
• Tighten securely to OEM guidance; avoid over-tightening which can damage threads

Spark electrode with a 29 inch female terminal.
