Parts for Thermador CJ302UB: 05 - Upper Plenum Parts

This mounting bracket secures appliance components in place to restore proper alignment and operation. It replaces a worn or damaged bracket to help reduce rattling, misalignment, or loose fittings in the affected assembly. What it does:

• Provides a stable anchor point for internal panels or assemblies
• Restores correct positioning to reduce noise and vibration caused by a loose bracket
• Prevents further wear on adjoining parts by securing connections
• Compatible with the OEM mounting location to maintain factory fit and function

• Inspect surrounding fasteners and mounting points; replace any stripped screws or damaged clips
• Use appropriate hand tools; avoid overtightening to prevent strip-out or deformation
• Disconnect power to the appliance before accessing internal components

Oven won't heat or shuts off during use? This thermal fuse cuts power when temperature exceeds safe limits. Moderate DIY repair with multimeter testing.

Fix a loud humming or buzzing noise from your wall oven control panel. This low-voltage transformer powers the control board and related circuits.

This is a thermal fuse designed to protect the microwave's electrical circuit from overheating. It acts as a safety device that breaks the circuit if internal temperatures exceed safe limits. Replace this fuse if your microwave suddenly stops working or loses all power, as a blown thermal fuse is a common cause of a completely dead unit.

This spacer positions and supports internal components to maintain correct alignment and clearance. It helps keep parts stable and reduces wear for reliable appliance operation. What it does

• Creates a consistent gap or offset between parts to ensure proper fit and movement.
• Helps prevent rubbing or binding that can cause noise or premature wear.
• Stabilizes panels and assemblies to reduce vibration and rattling.
• Supports correct alignment during reassembly after maintenance or part replacement.

• One spacer as shown.

• Disconnect power (and water if applicable) before accessing internal components.
• Inspect surrounding fasteners and mating surfaces; replace any damaged hardware.
• Press or fasten spacer into position per service instructions; do not force or alter the part.

This is a high voltage capacitor used in the electronic control or microwave cooking section of a range or oven. It stores and releases electrical energy to help power components that require high voltage. Replace this capacitor if the oven or range displays error codes, fails to heat properly, or if the control board is malfunctioning due to a faulty capacitor.
