Parts for Thermador CT130: 09 - Plenum Assembly Parts

This part has been discontinued by the manufacturer and is no longer available.

Welded plenum assembly for wall ovens. This metal air distribution chamber directs heated air throughout the oven cavity. Replace if cracked or damaged.

This discharge adapter connects the appliance's drain hose to the drain or pump outlet, restoring a secure path for wastewater and preventing leaks. Fits the factory connection point to ensure correct hose alignment and sealing. What it does:

• Provides a sealed connection between the appliance drain/pump outlet and the drain hose
• Prevents leaks and water dripping at the hose connection
• Helps restore proper drainage when the original adapter is cracked, worn, or missing
• Matches OEM connection dimensions to maintain proper hose routing and fit

• Disconnect power to the appliance and turn off water supply before starting
• Inspect hose and clamps; replace clamps or hose if damaged for a reliable seal
• Push adapter fully onto the outlet and secure hose with a clamp per manufacturer guidance

Phillips pan head mounting screw for cooktops and ranges. Replace this zinc-coated fastener if lost, stripped, or corroded during appliance repair.

Fix a non-working oven buzzer or timer with this relay switch. Controls timer alert functions in wall ovens. Direct replacement part for common timer issues.

This part has been discontinued and is no longer available.
