Parts for Thermador TSS36QBB: 29 - Icemaker Page 2 Parts

A replacement heat exchanger that helps remove heat from the refrigerator cooling circuit so the appliance can maintain proper internal temperatures. Restores proper refrigerant flow and supports consistent cooling performance. What it does:

• Circulates refrigerant through the evaporator circuit to absorb heat from the fresh-food compartment
• Helps the system reach and maintain target cooling temperatures
• Commonly replaced when corrosion, leaks, or physical damage reduce cooling efficiency
• Required if symptoms include weak cooling, frost pattern changes, or visible refrigerant leakage

• Disconnect power and follow all safety procedures before servicing
• Inspect surrounding tubing and fittings for damage or corrosion; replace any compromised components
• Use proper leak-testing and vacuum procedures when recharging the system

This tube, fill heater is the inlet heater tube that helps warm incoming wash water during the fill cycle so the dishwasher reaches and maintains proper wash temperatures for better cleaning performance. Designed as a direct-replacement service part. What it does:

• Heats or transfers heat to incoming fill water so washes start at a warmer temperature
• Helps maintain expected wash temperatures for improved cleaning results
• Supports normal fill-cycle operation and prevents cold-water-related performance issues
• Faulty unit can cause poor cleaning or heater-related error indications

• One tube, fill heater

• Disconnect power and shut off the water supply before starting any repair
• Access typically requires removing outer panels or the lower front kickplate
• Inspect seals and connections for leaks during reassembly; replace any damaged fasteners or gaskets

This mounting bracket secures the dishwasher water inlet valve to the appliance frame, keeping the valve stable so it can open and close reliably during cycles. It helps prevent valve movement and vibration that can cause noise or leaks. What it does:

• Holds the water inlet/fill valve in the correct position on the appliance frame
• Reduces valve vibration and noise during operation
• Helps maintain a secure seal at valve fittings to reduce leak risk
• Supports reliable water flow by keeping valve alignment stable

• One mounting bracket for the water inlet valve

• Disconnect power and shut off the water supply before starting work
• Use appropriate hand tools; reinstall or replace mounting fasteners as needed
• Watch for sharp edges on the appliance chassis and wear protective gloves
• Test for leaks and proper fill operation after reinstalling and restoring power/water

This ice maker assembly produces and harvests ice for compatible refrigerators, replacing a failed or damaged ice-making unit to restore normal ice production and cycling. Designed as a direct-replacement service part for units that use this OEM assembly. What it does:

• Forms, freezes, and harvests ice automatically as part of the freezer's ice-making cycle.
• Common symptoms it addresses: little or no ice production, ice maker not cycling, or ice trays not filling.
• Works with the refrigerator's water inlet and control signals to dump ice into the bin when ready.
• Replaces a defective ice-making module to stop intermittent operation or visible damage to the ice tray.

• Disconnect power and shut off the water supply before beginning replacement.
• Remove the ice bin and interior trim panels as needed to access the ice maker; keep track of mounting screws.
• Disconnect the wiring harness and water inlet tube carefully; avoid forcing connectors or pinch points.
• After installation, restore power and water, check for leaks, and run the ice-maker test/diagnostic cycle per the refrigerator's service instructions.
