Parts for Kitchenaid KJA13ASANA0: 02 - Attachment Parts

This adapter connects the refrigerator water supply to the dispenser or ice maker, providing a secure path for water flow to the ice/water system. It restores a proper sealed connection to help prevent leaks and restore water delivery. What it does:

• Provides a threaded/press connection between the household water line and the appliance inlet
• Replaces a damaged, corroded or leaking fitting that can cause water loss
• Helps restore reliable water flow to the ice maker or door dispenser
• Commonly used when the original adapter is cracked, stripped, or fails to seal

• One adapter

• Turn off the refrigerator and shut off the water supply before starting
• Drain residual water from the line and place a towel to catch drips
• Tighten fittings to manufacturer torque recommendations; avoid overtightening which can damage threads
• After installation, turn on water and check all connections carefully for leaks

This shaft adapter connects the appliance motor shaft to the slicing assembly so the slicer blade or accessory turns securely for consistent slicing performance. It restores proper engagement between the drive shaft and slicer attachment. What it does:

• Couples the motor drive shaft to the slicer blade/attachment so the blade rotates when the unit is switched on
• Ensures correct alignment and secure fit to reduce wobble or slipping during use
• Helps restore slicing function when the attachment will not engage or spin
• Fits the slicing assembly interface to transmit drive force from the motor

• Disconnect power before servicing to avoid injury
• Handle blades and slicing attachments carefully — use protective gloves
• Slide the adapter onto the drive shaft and align with the slicing assembly; ensure a snug, secure fit before use
• Test operation at low speed after installation to confirm proper engagement

This pusher fits into the feed tube to guide ingredients safely and engage the cover interlock. Replace a cracked or missing pusher to restore safe operation and smooth, controlled feeding during slicing or shredding.

• Guides food down the chute while keeping hands away from sharp blades/discs
• Completes the lid/bowl interlock so the motor runs only when properly assembled
• Helps maintain even, consistent feeding for better cutting results
• Common symptoms: unit won't start unless pressure is applied to the pusher, uneven feeding, or visible cracks/missing pusher

• Unplug the appliance before servicing
• Remove the lid and old pusher; clean the feed tube area
• Align and insert the new pusher without forcing; ensure it seats fully to engage the interlock
• Handle cutting blades and discs carefully—they are sharp

This pusher is a small molded actuator used in select Whirlpool appliances. It restores positive, reliable engagement between moving parts so the related mechanism operates smoothly and consistently after the original pusher becomes worn, cracked, or lost.

• Transfers motion to engage a lever, gate, or switch within the assembly
• Helps guide and align adjacent parts for smooth, consistent operation
• Reduces binding and misfeeds that can lead to jams or intermittent function
• Typical symptoms: mechanism won't activate, sticking or jamming, intermittent operation, visible damage to the original pusher

• Disconnect power (and water, if applicable) before servicing
• Access the assembly and note the original pusher's orientation; take a reference photo
• Release tabs or fasteners carefully to avoid cracking nearby plastic parts
• Seat the new pusher fully and verify free movement before reassembly

This is the work bowl for a food processor. Replacing a worn or cracked bowl restores safe locking with the lid and base so blades/discs can operate properly and ingredients stay contained during processing.

• Contains ingredients during chopping, mixing, and slicing
• Locks to the base and interfaces with the lid/pusher to complete the safety interlock
• Guides the drive shaft for blades and discs
• Common fix for cracks, leaks, broken tabs/handle, or a processor that won't start because the bowl won't lock

• Disconnect power before servicing
• Remove the lid, pusher, and any blade/disc; lift off the old bowl
• Seat the new bowl on the base and twist to lock; then lock the lid/pusher to engage the interlock
• Wash and dry the new bowl before first use
