Parts for Kenmore 790.70613210 (79070613210, 790 70613210): Backguard Parts

This door hinge cover shields and protects the refrigerator hinge area from dirt and damage while giving the hinge a finished appearance. Replaces a worn, cracked, or missing cover to restore proper fit and appearance. What it does

• Covers and protects the door hinge assembly from debris and accidental contact
• Helps maintain a finished look by hiding hinge hardware and mounting fasteners
• Prevents sharp edges from being exposed, reducing snag and scratch risk
• Commonly replaced when cracked, broken, or missing after impact or wear

• One door hinge shield

• Remove power and open the door before servicing to prevent injury
• Typically installs with a few screws or clips—retain original fasteners unless replacement specified
• Handle part carefully to avoid scratching painted surfaces; align shield before tightening

This is the adhesive graphic that labels the buttons on the electronic control panel. Replacing a worn, peeling, or unreadable overlay restores a clean look and makes the keypad labels easy to see again.

• Identifies control functions on the electronic oven/range panel
• Adheres to the control face; no electronics are included
• Common fix for worn-off text, bubbling/peeling edges, or cracked graphics
• Helps refresh the panel's appearance after damage or heavy cleaning

• Disconnect power to the appliance before starting
• Remove knob(s)/trim as needed to access the existing overlay
• Carefully peel off the old overlay and clean the surface of residue
• Align and apply the new overlay; press firmly to bond without bubbles

The Clock/Timer is an OEM replacement part for Frigidaire ranges. It allows for precise time and temperature settings to be entered and displayed for oven functions.

As a digital module, causes for failure may include corrupted firmware over time or water/debris intrusion damaging circuits. Backlight failure is common after extended hours of usage.

Symptoms consist of:

• Inaccurate time displaying/keeping
• Timer functions like pre-heating not engaging
• Corrupted or non-responsive touch controls
• Faint or no display illumination

This OEM Frigidaire replacement part is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Rocker Switch is an OEM part for Frigidaire ranges and ovens. It is responsible for turning the interior oven light on and off. The light switch allows visibility of the oven cavity for viewing food during the cooking process.

Causes can include normal wear and tear over time, exposure to heat inside the oven cavity, or accidental damage.

Symptoms of a bad oven light rocker switch include:

• The oven light failing to illuminate when the door is opened
• The light remaining on even when the door is closed
• An inconsistent or flickering oven light
• The switch itself becoming loose, cracked, or non-responsive

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This control knob replaces a worn or missing knob on your range or cooktop. It restores a secure grip and clear selection so you can set burner or oven functions smoothly and accurately. What it does

• Attaches to the control shaft to adjust burner or oven settings
• Provides a clear pointer and positive feel for accurate selection
• Replaces knobs that are cracked, stripped, loose, or missing
• Helps ensure smooth turning and proper engagement with the control

• 1 control knob

• Disconnect power; for gas units, also shut off the gas supply
• Pull the old knob straight off the control shaft
• Align the new knob with the shaft shape and press straight on—do not force
• Verify proper orientation and operation before use

This trim is a decorative finish piece for select ranges and wall ovens. It covers gaps and raw edges for a clean look and helps keep adjacent panels properly seated when the original becomes cracked, bent, or missing.

• Provides a finished appearance by covering exposed edges or gaps
• Helps maintain alignment of nearby panels or glass
• Replace if cracked, warped, missing, or no longer seats securely
• Common symptoms include loose/rattling panels and exposed or sharp edges

• Disconnect power; for gas models, also shut off the gas supply
• Wear gloves—edges can be sharp
• Remove old trim and transfer/reuse original screws or clips
• Align the new trim and secure with existing fasteners; confirm proper fit before reassembly

This repair parts list is the parts diagram and number reference used to identify replacement components and locations on the appliance. Keep it for ordering parts and planning repairs. What it does:

• Shows exploded diagrams and part numbers to help locate the correct replacement parts
• Simplifies ordering by matching parts to factory part numbers
• Helps diagnose where a failed component is installed so you can describe issues accurately
• Useful for service technicians and DIYers as a quick reference during repairs

• This is a reference document, not an installation or repair instruction manual
• Keep the sheet with your appliance paperwork or with the service kit for easy access
• For actual repairs, follow manufacturer instructions and disconnect power before servicing

This is a replacement mounting screw used to secure the dual safety valve assembly on compatible gas ranges and ovens. It restores proper fastening so the valve stays firmly in place during operation. What it does

• Secures the safety/dual gas valve to the appliance chassis or manifold
• Prevents valve movement that can interfere with burner operation or alignment
• Commonly replaced when original screw is missing, stripped, or damaged
• Matches OEM thread size and length for correct fit and retention

• One (1) screw, size 10-16 x 0.486

• Disconnect power and shut off gas supply before starting work; follow all safety procedures
• Thread carefully to avoid cross-threading; do not overtighten — snug to OEM torque specification
• Inspect surrounding mounting holes and hardware; replace any stripped or damaged parts for a secure fit

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
