Parts for Kenmore 790.75603700 (79075603700, 790 75603700): Backguard Parts

This oven thermostat senses and regulates oven temperature so food cooks evenly and the range reaches set temperatures. It replaces a failed temperature control to restore accurate heating and cycle behavior. What it does:

• Closes and opens the control circuit to maintain the oven at the selected temperature
• Can correct symptoms such as oven not reaching set temperature, overheating, or excessive cycling
• Works with the oven's control system and heating elements to stabilize bake and broil operations
• Mechanical design — avoid bending or damaging the sensing element/capillary

• One oven thermostat

• Disconnect power to the appliance before starting any service
• Handle the thermostat and sensing element carefully; do not kink or sharply bend the capillary
• Verify proper thermostat mounting and oven cavity seals for accurate temperature control

This interior refrigerator light provides bright, even illumination so you can see food and settings clearly while the door is open. Designed to fit the factory light location and restore proper interior lighting. What it does

• Illuminates the refrigerator compartment for improved visibility
• Replaces a burned-out, flickering, or dim interior light
• Helps locate food and read controls without removing items
• Works with the factory light housing and switch to operate when the door opens

What's included One interior refrigerator light Install notes

• Disconnect power to the appliance before starting any work
• Handle glass or bulb components carefully to avoid breakage and injury
• Use the exact part number for compatibility; do not force if fitment differs

If your range won't respond to buttons or displays error codes, this electronic control board manages user controls and core functions. Restores reliability.

Replaces a worn, cracked, or missing range control knob. Restores safe operation of burners and oven functions. Graphite finish matches original knob.

This truss-head machine screw secures a switch to its mounting bracket or panel. Replacing a worn or missing screw restores a solid, aligned switch fit for reliable operation.

• Fastens the switch body to a bracket or chassis panel
• Helps keep the switch aligned for consistent actuation
• Replaces stripped, corroded, or missing mounting hardware
• Common symptoms: loose or wobbly switch, misalignment, rattling or vibration around the switch area

• Disconnect power to the appliance before servicing
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Verify thread size and length match the original hardware
• If multiple screws secure the switch, replace them in a consistent pattern to maintain alignment

This repair parts list is the printed parts diagram and reference sheet that shows the component names and part numbers for a specific appliance, helping technicians and owners identify replacement parts faster. What it does

• Provides an exploded-parts diagram and corresponding part names/numbers for accurate part identification
• Reduces diagnostic time by clearly showing part locations and relationships
• Useful for service technicians and knowledgeable owners during disassembly or ordering

• This is an informational document, not a functional appliance component
• Keep with the appliance or service records; do not install or modify
• Use the diagram and part numbers to order or verify replacement parts

10-24 x 1/2 inch machine screw that secures temperature probe and thermistor brackets to cooktop, oven, and range chassis. Replace if missing or stripped.

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.
