Parts for Kenmore 790.97403410 (79097403410, 790 97403410): Backguard Parts

This door hinge cover shields and protects the refrigerator hinge area from dirt and damage while giving the hinge a finished appearance. Replaces a worn, cracked, or missing cover to restore proper fit and appearance. What it does

• Covers and protects the door hinge assembly from debris and accidental contact
• Helps maintain a finished look by hiding hinge hardware and mounting fasteners
• Prevents sharp edges from being exposed, reducing snag and scratch risk
• Commonly replaced when cracked, broken, or missing after impact or wear

• One door hinge shield

• Remove power and open the door before servicing to prevent injury
• Typically installs with a few screws or clips—retain original fasteners unless replacement specified
• Handle part carefully to avoid scratching painted surfaces; align shield before tightening

The Indicator Light is an OEM part for Frigidaire ranges. This light is designed to signal when the range or oven is in operation, providing a visual cue for safety and usability. It typically illuminates when the burners or oven are on, ensuring users are aware of active heating elements.

Causes of a bad indicator light can include electrical malfunctions, wear and tear over time, or damage from power surges or excessive heat.

Symptoms of a bad indicator light include:

• Light not illuminating when the range or oven is in use
• Flickering or inconsistent illumination
• Light staying on constantly, even when the range or oven is off
• Visible damage or discoloration of the light

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This electronic control panel replaces the front user interface that houses buttons, displays and controls for oven/cooktop functions, restoring normal operation and clear status feedback for the appliance. What it does:

• Provides the touch/keypad and display area used to set temperature, timers and cooking modes
• Sends user commands to the range/oven control board so selected functions run as intended
• Common symptom fix: unresponsive or intermittent buttons and controls
• Common symptom fix: blank, faded or unreadable display elements
• Works with the appliance's main control to update settings and show status

• Disconnect power to the appliance before starting any service to avoid electrical shock
• Installation typically requires removal of the front console/trim and careful disconnect of wiring harnesses
• Handle the display and ribbon/connector areas carefully to avoid damage

The Indicator Light Lens is an OEM part for Frigidaire ranges. This component covers and protects the indicator light, which signals when a burner or the oven is on, providing a visual cue for users to ensure safe operation.

Over time, the indicator light lens can become damaged or discolored due to heat exposure, regular cleaning, or accidental impacts. Causes of a bad indicator light lens include cracking, warping, or clouding that obscures the light.

Symptoms of a bad indicator light lens include:

• The indicator light not being clearly visible
• Cracks or breaks in the lens
• Discoloration or cloudiness that diminishes the brightness of the light
• The lens becoming loose or falling off

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Infinite Switch is an OEM component specifically designed for Frigidaire ranges. It controls the burners, allowing users to easily adjust heat levels and select different cooking zones.

Causes of a bad infinite switch can include wear and tear over time, exposure to moisture or impacts from cookware, or underlying issues with the control board or wiring.

Symptoms of a bad infinite switch include:

• Burners failing to ignite or heat up when selected
• Inability to change burner heat levels
• Flickering or non-responsive control panel lights
• Cooktop controls becoming unresponsive

Replacing the switch with this OEM Frigidaire part can help restore full functionality. It is compatible with freestanding and slide-in electric cooktop models. This replacement switch is also compatible with ranges sold under the Whirlpool, Roper, and Maytag brands.


The Surface Element Control Switch is an OEM part for Frigidaire electric ranges and cooktops. It is a critical component that controls the operation of the surface heating elements, allowing you to turn them on and off, and select the desired heat settings.

Symptoms of a faulty Surface Element Control Switch include:

• Inability to turn on or control the surface heating elements
• Inconsistent or erratic heat output from the elements
• Elements not cycling on and off properly or staying on continuously
• Heating elements not responding to temperature adjustments

Causes of a bad Surface Element Control Switch can include electrical faults, physical damage, or wear and tear over time due to frequent use and exposure to high temperatures.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This truss-head machine screw secures a switch to its mounting bracket or panel. Replacing a worn or missing screw restores a solid, aligned switch fit for reliable operation.

• Fastens the switch body to a bracket or chassis panel
• Helps keep the switch aligned for consistent actuation
• Replaces stripped, corroded, or missing mounting hardware
• Common symptoms: loose or wobbly switch, misalignment, rattling or vibration around the switch area

• Disconnect power to the appliance before servicing
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Verify thread size and length match the original hardware
• If multiple screws secure the switch, replace them in a consistent pattern to maintain alignment

This is a replacement mounting screw used to secure the appliance power/control board, restoring a solid electrical board connection and preventing vibration or loose contacts. Ideal for repairs where the original screw is missing or damaged. What it does:

• Fastens the power/control board to the appliance chassis to keep connections stable
• Helps prevent board movement that can cause intermittent electrical issues or noise
• Restores proper mounting after service or component replacement

• Turn off and unplug the appliance before starting any repair
• Use appropriate screwdriver and avoid over-tightening to prevent board or thread damage
• Wear eye protection and keep small parts away from children and pets

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
