Parts for Bosch HMV3022U/01: Base Assembly Parts

A replacement circulation pump motor that restores water movement in the dishwasher's wash system for proper cleaning and rinsing. Installs in the pump assembly to replace a worn or failed motor and stop noisy or non-operating pumps. What it does:

• Drives the dishwasher's water circulation/pump assembly so wash arms receive proper water flow.
• Common symptom: little or no water spray during the wash cycle or poor cleaning performance.
• Common symptom: loud grinding, humming, or the pump not starting when the cycle runs.
• Works as the rotating motor portion of the pump; requires correct pump housing and seals for a leak-free installation.

• One motor

• Disconnect power and turn off water supply before beginning repair.
• Inspect pump housing, gaskets, and impeller during replacement; replace worn seals to prevent leaks.
• Handle the motor and electrical connections carefully; ensure connectors are fully seated and secured.
• After installation, restore power and run a short cycle to check for proper operation and leaks.

This light socket holds the appliance bulb and provides a secure electrical connection, restoring reliable interior lighting. Replace a cracked, heat-damaged, or loose socket to fix lights that don't come on even with a good bulb.

• Provides the electrical contacts and mechanical support for the light bulb
• Helps resolve no-light or intermittent flicker when the bulb and switch are OK
• Common failure signs: discoloration, melting, burn marks, or loose/broken contacts
• Restores dependable illumination in the designated lighting location

• Disconnect power at the breaker and allow the appliance to cool before servicing
• Wear cut-resistant gloves and eye protection; handle bulbs by the base, not the glass
• Note wire positions and transfer connectors one at a time to the new socket
• Seat the bulb fully and test operation before reinstalling any covers or panels

This replacement lamp restores proper lighting in your appliance, making it easier to see contents and monitor cycles. Install it when the original bulb burns out or flickers to bring clear, reliable illumination back.

• Provides illumination when the appliance's light circuit or door switch activates
• Common symptoms: no light, intermittent or flickering light, or a visibly failed bulb
• Heat, age, vibration, or moisture can cause the lamp to fail
• A new lamp typically resolves lighting issues if the socket and switch are sound

• Disconnect power at the breaker or unplug before servicing
• Allow the area to cool fully before opening the light cover
• Handle the glass with clean gloves or a cloth to avoid skin oils
• Install the exact replacement specified for your model; do not exceed the manufacturer's rating

This wire grid is a direct-replacement support rack that restores proper cookware and bakeware support in your appliance. It provides a stable, elevated surface for even air circulation and consistent cooking results. What it does:

• Replaces a bent, rusted, or missing wire support to restore stable cookware placement
• Helps maintain even heat circulation by elevating trays and pans
• Prevents direct contact between cookware and the appliance bottom, reducing scorching
• Useful when original grid coating has worn or protective finish is compromised

• One wire grid

• Allow the appliance to cool and disconnect power before replacing
• Slide the grid into the existing rack supports; no special tools typically required
• Wear gloves to protect hands from sharp edges or residual grime
• Before using the appliance, ensure proper seating and clearance.

The Grease Filter is an OEM part for Bosch microwaves. It functions to catch and contain any splatters or grease that may result from cooking foods with high fat or oil content in the microwave. This helps keep the microwave interior clean and protects components from residue buildup.

Causes of a bad grease filter can include damage or wear over frequent use and cleaning cycles. Failing to replace filters at recommended intervals can also cause them to become excessively dirty or clogged.

Symptoms of needing a new grease filter include:

• Grease splatters accumulating inside the microwave rather than being caught by the filter
• Unpleasant burnt or smoky smells generated during cooking
• Reduced cooking power or effectiveness due to blocked ventilation

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.
