Parts for Ge AZ58H07EACM1: 02 - Base & Chassis Parts

A condenser plate that secures and shields the refrigerator condenser assembly for stable operation and proper airflow. Replaces a damaged or missing plate to help maintain condenser protection and consistent cooling performance. What it does:

• Secures the condenser assembly and related components to the cabinet/frame
• Protects the condenser coil from debris and physical damage
• Helps direct airflow around the condenser for efficient heat dissipation
• A failing or missing plate can allow vibration, rattling, or reduced cooling effectiveness

• One condenser plate

• Disconnect power to the appliance before starting any repairs
• Use care handling the plate—edges may be sharp
• Retain and reuse existing mounting hardware if compatible; verify hole alignment before tightening

This bulkhead is the replacement housing piece that supports and aligns internal rotating parts and helps direct airflow in the appliance. Replacing a worn or damaged bulkhead restores proper drum alignment and reduces rubbing or air leaks. What it does:

• Supports and locates the drum/rotating assembly to maintain proper alignment
• Provides a mounting surface and pathway for airflow inside the appliance
• Prevents rubbing and excess vibration caused by damaged or warped housings
• Helps eliminate symptoms such as squealing, rubbing noises, uneven spinning, or reduced airflow

• Disconnect power and gas before beginning service
• Follow the appliance service manual for disassembly and reassembly steps
• Inspect adjacent bearings, seals, and fasteners; replace if worn to prevent repeat failure
• Use proper tools and take care not to damage sealing surfaces or wiring during installation

This wire fixing band is a small retainer clamp that secures wiring harnesses and individual wires to appliance chassis to prevent rubbing, pinching, or accidental disconnection. It helps protect wiring from damage and reduces electrical faults. What it does:

• Holds wiring harnesses and loose wires in place to prevent contact with hot or moving parts
• Reduces wear from vibration and movement that can cause frayed insulation or shorts
• Helps maintain safe routing of wires to avoid pinch points and strain on connectors
• Commonly used where a simple clipped band or strap is needed to fasten wires to sheet metal

• Inspect surrounding wiring and connectors before installation; replace damaged wires or insulation
• Secure the band to the designated chassis hole or stud without over-tightening to avoid crushing wires
• Disconnect power before accessing wiring and follow all appliance safety procedures

This D filter is the dryer lint screen that traps lint and debris from the drying drum, helping maintain proper airflow and reduce lint build-up for more efficient drying. Fits dryers that use a D-shaped lint screen. What it does:

• Captures lint, fibers and small debris to prevent them from re-entering the drum or vent
• Helps maintain airflow to avoid longer dry times and poor drying performance
• Reduces lint buildup that can contribute to overheating or vent blockages
• Works as the removable screen you clean between cycles to keep the dryer running efficiently

• One D filter

• Disconnect power before inspecting or replacing the lint screen
• Remove the old screen by pulling it out of the housing, clean the housing, then insert the replacement until it seats fully
• Clean the screen after each load; replace if cracked, warped or damaged
• If dryer still shows poor airflow after replacement, inspect the venting system for blockages or damage
