Parts for Ge ZDP304LP4SS: 04 - Body Parts

This lubricant/cleaner is used during service of cooking appliances to dissolve residue and provide light lubrication on small moving parts. It helps restore smoother operation of control shafts and valves when burner knobs feel stiff or sticky. What it does:

• Cleans deposits and old grease from control shafts and valve components
• Provides light lubrication to reduce friction and sticking
• Helps address symptoms such as hard-to-turn burner knobs or rough valve rotation
• Supports preventative maintenance during range/cooktop service

• Lubricant/cleaner

• Disconnect power and shut off gas; allow the appliance to cool before servicing
• Work in a well-ventilated area and keep away from open flames or ignition sources
• Apply sparingly per service instructions; avoid contact with igniters, electrical components, and flame ports
• Replace any worn or leaking valve—do not rely on lubricant/cleaner to correct a leak

This wire bushing protects appliance wiring where wires pass through metal or plastic panels, helping prevent chafing and shorts. It restores a safe insulating barrier to wiring harnesses and terminals. What it does:

• Cushions and isolates wires where they pass through openings to prevent abrasion and wire damage
• Helps stop rubbing that can wear insulation and cause arcing or shorts
• Reduces risk of intermittent power, blown fuses, or burning smells from damaged wiring
• Restores proper routing and strain relief for affected harnesses

• Remove power to the appliance before accessing wiring; disconnect power at the breaker or unplug.
• Inspect surrounding wire insulation and harness for damage; replace any wires that show charring or exposed conductors.
• Push the bushing into the opening until seated, then route the wire through the bushing to ensure a snug fit.

This relay board assembly routes line voltage to the appliance's assigned components as directed by the main control. Replacing a failed board restores consistent power delivery and dependable heating/ignition on the affected side.

• Switches power to loads assigned to the right-side circuit group
• Common symptoms: no heat/ignition on that side, components won't energize, intermittent operation, or visible/burnt board damage
• Restores proper sequencing of components when commanded by the electronic control

• Disconnect electrical power at the breaker; shut off gas supply if applicable
• Use ESD protection; avoid touching solder joints or relay contacts
• Label/photograph all wiring; move connectors to matching terminals; transfer any mounting hardware from the original board
• Ensure all harnesses are fully seated and the board is secured before restoring power and testing

This switch sail assembly is the user-facing actuator that engages a range or cooktop control switch, letting you select heat settings and turn burners on or off. It restores tactile control when the original actuator is worn or broken. What it does:

• Replaces the plastic sail/actuator that interfaces with a control switch for safe, reliable operation
• Transfers knob movement to the internal switch so burners respond to your setting
• Commonly used when a control feels loose, slips, or fails to change settings
• Fits into the control panel and snaps or secures into the switch housing to make a firm connection

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Installation typically requires removing the control panel or trim and carefully disengaging the old actuator from the switch
• Handle plastic components gently to avoid breakage; correct orientation before reassembly

Size: 8-18 x 1/2 inch.

This anti-tip bracket secures a freestanding range or oven to the floor or wall to help prevent tipping during normal use, improving safety and stability. Simple, durable bracket designed to restore the factory anchoring point. What it does:

• Anchors the rear/base of a freestanding range to help prevent the unit from tipping forward
• Reduces rocking or shifting when opening heavy oven doors or sliding cookware
• Restores the proper mounting point after damage or missing hardware
• Helps address symptoms like a range that tilts or moves when pressure is applied

• One anti-tip bracket

• Follow the appliance OEM installation instructions; bracket mounts to floor or wall framing—locate a stud or secure to recommended substrate
• Turn off and disconnect power (and gas if applicable) and remove access panels as required before beginning work
• Use proper fasteners for your floor/wall material; do not rely on adhesive or weak anchors

This anti-tip brace secures the range to the floor or wall to help prevent the appliance from tipping forward when a heavy load is on an open oven door or when pressure is applied to the top edge. It restores a key safety restraint and helps stabilize the appliance. What it does

• Anchors the range to reduce forward tipping when the oven door is open or heavy items are placed on the door
• Helps prevent accidents and appliance movement during normal use
• Works with the range's built-in leveling and mounting points to provide a secure attachment
• Commonly replaced after a move, installation, or if the original bracket is damaged or missing

• One anti-tip brace

• Follow the appliance installation manual for correct placement and mounting location
• Unplug the appliance (or shut off power) and remove access panels as needed before installing
• Use appropriate fasteners for your floor/wall material; secure to framing or floor as specified

The Blower Tangential 45mm is an OEM part for GE gas ranges. It is the convection fan that circulates heated air within the oven cavity during convection cooking cycles.

Symptoms of a bad blower tangential include:

• Lack of airflow inside the oven
• Uneven baking and roasting results
• Inability to select convection cooking modes

Causes of failure can be worn bearings, burned out motor, or damage from excess heat over long-term use.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore gas range models.

This side support panel replaces a damaged or missing support on the appliance's side, helping secure and align the cabinet and trim so the unit sits solidly and looks finished after installation or service. What it does:

• Provides structural support for the side of the appliance cabinet and adjacent trim
• Helps maintain correct spacing and alignment next to countertops or panels
• Replaces a bent, warped, or corroded panel
• Reduces rattles or rubbing caused by a loose side assembly

• One side support panel

• Disconnect power; turn off gas supply before servicing
• Carefully pull the unit forward for side access; support it to prevent tipping
• Remove fasteners, transfer any clips/brackets from the old panel, and reinstall with existing hardware
• Wear cut-resistant gloves and verify clearances and level before final tightening

This access back panel covers the rear of the appliance to protect internal components and restore a finished appearance. It provides a secure mounting surface and keeps wiring and parts enclosed for safe operation. What it does:

• Covers and protects internal wiring, controls and components at the appliance rear
• Restores a finished exterior and helps prevent dust and debris entry
• Secures with factory mounting points to stop rattling or loose panels
• Replaces missing, bent, or corroded rear access panels that expose internal parts

• Disconnect power and pull the appliance away from the wall before installing.
• Use correct screws and hardware for secure mounting; verify alignment with factory holes.
• Handle edges carefully; wear gloves to avoid cuts.

This threaded connector secures or joins short sections of tubing or hose on select appliances, restoring a tight, reliable connection. Use when the original nipple is corroded, stripped, or leaking. What it does:

• Provides a secure, threaded connection between tubing, hose, or fittings
• Maintains a sealed joint to help prevent leaks at the connection point
• Replaces damaged or worn nipples that can cause loose fittings or loss of flow
• Commonly used where a short, durable threaded coupling is required

• One nipple

• Disconnect power and shut off water or gas supply before servicing
• Inspect mating threads and replace any damaged seals or washers
• Hand-start threads to avoid cross-threading, then tighten with the appropriate wrench
• After installation, restore supply and check carefully for leaks during a test run

This handle spacer positions the appliance handle at the correct distance from the door or panel for smooth operation. Replacing a worn or missing spacer restores proper standoff, alignment, and feel, and helps prevent rubbing, rattling, or looseness.

• Maintains proper spacing between the handle base and mounting surface
• Helps keep the handle aligned and secure
• Reduces rubbing or contact with the door/panel
• Common fix for a wobbly, misaligned, or scraping handle

• Unplug power and allow hot surfaces to cool before servicing
• Support the door/handle while removing mounting screws to prevent strain
• Note the spacer's position and orientation; reinstall the new spacer in the same location
• Tighten screws snugly; do not overtighten to avoid damage

The Wall Oven Capacitor Motor is an OEM part for GE wall ovens. Located inside the oven cavity, this motor is responsible for turning the convection fan which circulates hot air for even baking and roasting.

Symptoms of a bad capacitor motor include:

• Inability to select convection bake or roast features
• Uneven cooking results
• Lack of air circulation inside the oven
• Strange noises coming from the fan/motor area
• The convection fan not turning on

Causes of failure can be wear over time, damage from debris inside the oven, or occasional voltage fluctuations which can degrade motor components.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Screw is an OEM replacement part for GE refrigerators. Countless screws are used throughout the refrigerator to securely hold parts in place.

Symptoms of a bad or missing screw can include:

• Rattling or vibration noises coming from inside the appliance
• Doors or other parts that are no longer properly aligned
• Increased frost or cold air leaks due to compromised seals

Causes may include normal wear and tear over time, accidental damage or loss of a screw during repairs, or improper assembly leaving crucial screws omitted.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore refrigerators.
