Bosch 00487251 Bake Element (Small Oven) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others. See all items in Range / Cooktop / Oven Heating Element.

Cross Reference Information

Part Number 00487251 replaces AP2836982, 1051914, 15-10-233, 487251, PS8720942.

Description

This bake element heats the small oven cavity from below during Bake, delivering the radiant heat needed for preheating and consistent baking when the original element fails.

• Provides primary bake heat at the bottom of the small oven cavity
• Works with the oven control to preheat and maintain set temperature
• Common failure symptoms: no or weak bake heat, uneven baking, visible blistering/cracks, or a breaker trip when Bake is selected

What's included: One bake heating element for the small oven. Install notes:

• Disconnect power at the breaker before servicing
• Access is typically from inside the cavity; remove mounting screws, pull the element forward, and move wires one at a time
• Support wires so they don't retract into the insulation; avoid bending or stressing the new element
• Restore power and run a bake cycle to verify proper heating
