Parts for Electrolux EW30GC55PS1: 03 - Burner Parts

This water inlet valve controls the flow of water to the refrigerator ice maker and water dispenser, restoring normal water delivery for ice production and chilled-water dispensing. What it does:

• Opens and closes to route water to the ice maker and dispenser when requested.
• Replaces a worn or failed valve that can cause no water or no ice production.
• Can stop intermittent or constant water leaks originating at the valve assembly.
• Helps restore proper filling if the ice maker won't fill or the dispenser delivers weak/no water.

• Shut off the water supply and unplug the appliance before replacing the valve.
• Verify water lines and electrical connectors are seated and routed without kinks.
• Tighten fittings to manufacturer torque recommendations; hand-tighten then secure per OEM guidance to avoid leaks.
• After installation, restore water and power, then check for leaks and correct operation of the dispenser and ice maker.

This switch assembly replaces a worn or broken control switch to restore reliable on/off and function selection for the appliance. It provides the mechanical and electrical contacts needed for proper control operation. What it does:

• Replaces a failed control switch to restore appliance responsiveness
• Enables selection of settings and completes electrical circuits when actuated
• Commonly installed when a control no longer turns on, is intermittent, or has visible damage
• Matches OEM fit and mounting points for direct replacement

• One complete switch assembly as shown

• Disconnect power before starting any repair to avoid electrical shock
• Access may require removing panels or the control console; follow your model's service instructions
• Verify wiring location and routing before disconnecting; transfer connectors one at a time

The Ignitor Screw is an OEM component for Frigidaire ranges and ovens. It secures the igniter, a critical heating element that sparks to ignite the gas burner.

Causes of a bad ignitor screw can include damage or stripping of the screw head from repeated removal/installation of the igniter component over time.

Symptoms of a bad ignitor screw include:

• The igniter shaking loose and becoming disconnected
• Inability to properly tighten the igniter securely in position
• Lost or stripped screw

This genuine Frigidaire replacement screw restores secure mounting of the igniter. Proper fastening is necessary for consistent and reliable ignition of cooking appliances.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Replacement mounting bracket that secures internal appliance components to the cabinet or frame, restoring proper alignment and support. Helps reduce rattling and prevents loose or sagging parts for safer, quieter operation. What it does:

• Secures components or assemblies to the appliance frame to maintain proper alignment.
• Reduces movement and vibration that commonly cause rattling or intermittent contact.
• Helps prevent sagging or misalignment of attached parts that can affect operation.
• Simple, passive part — no electrical function.

• Disconnect power (and water, if applicable) before starting any repair.
• Use appropriate hand tools; inspect mounting holes and fasteners for damage or corrosion.
• Replace only the damaged bracket; do not overtighten fasteners to avoid cracking.

The Spark Module is an OEM part for Frigidaire gas ranges. It allows precise flame control for cooking. This module sends the necessary electrical currents to the igniters at each burner, which then spark to ignite the gas.

Causes of a bad spark module can include electrical failures, corrosion, or moisture damage, as well as wear and tear from normal use.

Symptoms of a bad Spark Module include:

• Burners failing to ignite despite being turned on
• Intermittent ignition or weak spark generation
• Continuous clicking sounds from the burner area even after ignition
• Unlit burners leading to gas smell, indicating incomplete combustion

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This burner assembly replaces a single surface burner on compatible gas ranges, restoring reliable heat for cooking. It provides the burner base, orifice support and connections needed to produce a steady flame when operating correctly. What it does:

• Holds and directs gas to the cooktop burner for ignition and steady flame
• Replaces worn or damaged burner hardware that can cause weak, uneven, or no flame
• Restores proper spacing and support for burner caps and grates
• Helps resolve ignition and heating issues when the burner component is the cause

• Disconnect the appliance from power and shut off gas supply before beginning work
• Basic hand tools typically required; some installations may require removing cooktop components
• Inspect seals and fittings for damage and replace if necessary to prevent leaks

This is a surface burner head for a gas range/cooktop. It distributes gas from the orifice to the burner ports, helping deliver an even flame and reliable ignition when the original head is clogged, damaged, or corroded.

• Channels gas through precision ports to create a stable, even cooking flame
• Works with the burner cap and igniter for quick, consistent lighting
• Typical symptoms: burner won't light or takes multiple clicks, uneven/yellow flames, weak flame, or popping/flare-ups
• Physical issues may include blocked ports, heavy corrosion, or a warped/stripped casting

• Disconnect power and shut off gas; let the cooktop cool completely
• Lift off the burner cap; remove mounting screw(s) if present and lift off the old head
• Clean mating surfaces/orifice area; set the new head squarely and secure with existing hardware
• Restore gas and power; verify proper ignition and flame pattern

This replacement surface burner head restores a steady, even flame on your gas cooktop. It mixes gas and air and distributes the flame evenly to help ensure reliable ignition and consistent cooking performance.

• Mounts over the orifice and channels gas/air through flame ports for even heating
• Helps resolve weak, uneven, or yellow flames and delayed ignition
• Can address clicking without lighting or burners that won't stay lit
• Durable cast construction designed for repeated heating cycles

• Disconnect power and shut off gas; allow the appliance to cool completely
• Remove grates and access the burner per your model; transfer any mounting hardware from the old part if needed
• Seat the new burner head squarely over the orifice and ensure proper alignment
• Restore gas and power; test for proper ignition and flame. If any gas connections were disturbed, check for leaks with soapy water.

This burner restores proper flame distribution and ignition performance in your gas cooking appliance, helping you achieve steady, even heat for reliable boiling, simmering, and searing. What it does:

• Directs gas from the orifice through burner ports for an even flame pattern
• Works with the igniter/electrode to light the burner
• Helps reduce symptoms like uneven or weak flame, delayed ignition, or flame that lifts or makes popping noises
• Can address issues where the burner won't light or only lights partially due to damage or blockage

• 1 burner

• Disconnect power and shut off gas before servicing
• Access the burner per your model's service instructions; transfer any required hardware from the old part
• Ensure proper alignment with the igniter and orifice; tighten fasteners securely
• Restore gas and power, then inspect flame; check for leaks if any gas fittings were disturbed

This ignitor orifice assembly routes gas to the burner so the ignitor can light the flame, restoring reliable ignition and efficient burner operation. It's a direct-replacement style part used on compatible gas ranges and ovens. What it does

• Controls and meters gas flow to the burner orifice so the ignitor can ignite the burner
• Restores consistent ignition when a faulty orifice prevents the burner from lighting
• Can correct weak or intermittent flames caused by a damaged or clogged orifice
• Works as part of the burner/ignition system

• One ignitor orifice assembly

• Turn off the appliance power and shut off the gas supply before starting work
• Handle and seat the orifice assembly carefully; do not overtighten fittings
• Check for proper sealing and ignition after installation; if you detect a gas smell or suspect a leak, shut off gas immediately
• If you are not comfortable working on gas appliances, have the part installed by a licensed service professional

This ignitor orifice assembly directs gas flow to the oven/burner igniter for reliable ignition and consistent flames. It replaces worn or clogged orifice parts to restore normal ignition performance. What it does:

• Regulates and channels gas to the igniter so the burner/oven will light
• Helps produce a steady, consistent flame for proper cooking temperatures
• Common repair when a burner or oven fails to ignite or has weak flame
• Prevents irregular ignition caused by damaged or blocked orifice passages

• One ignitor orifice assembly

• Turn off the appliance power and shut off the gas supply before starting
• Inspect fittings and seals for damage and test for leaks after installation (use approved leak-detection methods)
• Use appropriate tools and follow the appliance service manual for removal and reassembly

This ignitor orifice assembly replaces the oven's burner ignition component to help light the gas burner reliably and restore normal oven ignition. Designed to match OEM fit and function on compatible Frigidaire gas ovens. What it does:

• Provides the ignition pathway so the burner lights when the oven calls for heat
• Directs and meters gas at the burner ignition point for consistent ignition
• Addresses symptoms like the oven failing to light, delayed ignition, or intermittent ignition
• Works with the oven's safety and control systems to enable normal burner operation

• Shut off gas supply and electrical power before servicing; verify both are off
• Only install in gas ovens that use this specific assembly;

This ignitor orifice assembly positions the oven burner orifice and supports proper ignition for gas ovens. Replacing a worn assembly can restore reliable burner lighting and help the oven reach and hold temperature. What it does:

• Secures and aligns the burner orifice so gas flows correctly to the ignitor/pilot
• Enables consistent ignition of the oven burner
• Helps resolve symptoms like the oven failing to light, repeated clicking without ignition, or an unstable/weak flame
• Works as a direct replacement for the oven's original orifice/ignitor mounting component

• Turn off gas supply and disconnect power before beginning any work.
• Basic hand tools are typically required; follow OEM instructions for safe removal and reinstallation.
• If you smell gas, stop immediately.

The Regulator is an OEM part for Frigidaire cooktops. It is responsible for regulating the flow and pressure of gas entering the appliance, ensuring safe and efficient operation.

A bad regulator can be caused by faulty internal components, wear and tear over time, or damage due to improper handling. Signs of a faulty regulator include uneven heating, weak flame, or gas leaks.

Symptoms of a bad regulator can include:

• Uneven heating of burners or oven
• Weak or inconsistent flame
• Gas leaks around the regulator

This Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

The Bushing is an OEM part for Frigidaire cooktops. This part serves as an interface between the control knob and the appliance, ensuring smooth operation and protecting both the knob and the control panel from wear and tear. The bushing fits snugly around the valve's stem, reducing friction and providing stability as the knob is turned to adjust the heat settings of the cooktop.

Causes of a bad Bushing can include degradation from frequent use, exposure to high heat, or accidental damage during cleaning or use, which can lead to the bushing becoming loose or worn out.

Symptoms of a malfunctioning Bushing include:

• Loose-feeling knobs that wobble or are difficult to turn
• Excessive wear or visible damage to the knob or panel area
• Difficulty in achieving precise temperature control
• Unusual noise when turning the knobs

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.
