Parts for Ge GHDS835ED0MC: 04 - Cabinet Parts

This exhaust duct channels cooking exhaust from the appliance to the home vent system, restoring proper airflow and helping reduce smoke, steam and cooking odors in the kitchen. What it does:

• Directs exhaust air from the appliance to the venting system to maintain proper airflow.
• Helps reduce cooking smoke, steam and odors by providing a clear path to the outside.
• Prevents moisture buildup and improves ventilation performance when intact and properly installed.
• Worn, crushed or disconnected ducts can cause weak exhaust, lingering odors, excess steam or increased noise.

• Disconnect power to the appliance and follow all safety and grounding instructions before servicing.
• Use basic hand tools and gloves; avoid sharp edges on metal ducting.
• Do not modify the part; if replacement requires changes to venting, refer to the appliance manual.

Package of 12

This leveling leg threads into the base of your appliance to provide a stable, adjustable footing. Replacing a worn or missing leg helps keep the cabinet level, reducing vibration and noise for smoother, safer operation.

• Adjusts height so the unit can be leveled on uneven floors
• Maintains solid floor contact to minimize rocking or walking
• Helps reduce vibration and rattling noises during operation
• Signs you need this part: appliance wobbles, sits unevenly, or a foot is missing/damaged

• Disconnect power; for gas units, also shut off the gas supply
• With assistance, carefully tilt or raise the appliance to access the leg
• Unscrew the old leg and thread in the new leg by hand; use a wrench if needed
• Level the unit front-to-back and side-to-side; ensure all legs firmly contact the floor

The Door Latch is an OEM part for GE dryers. This part ensures the dryer door stays securely closed during operation, activating the safety switch to allow the dryer to operate. The latch mechanism engages with the door strike to lock the door, preventing it from opening while the dryer is running, which is essential for both safety and proper functioning of the appliance.

Causes for replacement can include normal wear and tear, accidental damage, or a misalignment that prevents the door from securely latching.

Symptoms of a bad Door Latch include:

• The dryer door doesn't stay closed during cycles.
• Difficulty in starting the dryer due to the door not activating the safety switch.
• Visible wear or damage to the latch mechanism.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Door Switch is an OEM part for GE dryers, designed to ensure the dryer does not operate when the door is open. This safety feature is crucial for preventing accidents and ensuring the appliance operates efficiently and safely. The switch signals the dryer's control system about the status of the door—if it's open or closed—thereby allowing or preventing the start of a drying cycle.

Causes of damage to the door switch often include mechanical wear from repeated use, accidental damage from loading or unloading, or electrical issues such as short circuits.

Symptoms of a bad Door Switch include:

• The dryer not starting when the door is closed
• The dryer continuing to run when the door is opened
• Unusual noises or the dryer stopping mid-cycle

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This replacement screw secures appliance panels and internal components per your model's hardware list. Replace lost or stripped screws to keep assemblies tight, reduce vibration and rattles, and maintain proper alignment.

• Fastens brackets, covers, and sheet-metal panels as specified in the parts diagram
• Restores proper fit when an original screw is missing, stripped, or damaged
• Helps eliminate rattling or vibration from loose hardware
• Keeps components safely in place during operation

• Disconnect power to the appliance before servicing
• Match length, head style, and thread to the original; install in the same location/quantity
• Start threads by hand to avoid cross-threading; tighten with the correct driver
• Do not overtighten, especially into plastic or thin sheet metal

A small rubber-lined washer that cushions and electrically isolates connections to reduce metal-on-metal contact and damp vibration. Helps protect parts and maintain proper spacing for reliable operation. What it does:

• Cushions fasteners and mounting points to reduce vibration and noise
• Provides electrical insulation between metal components
• Prevents wear from direct metal-to-metal contact
• Keeps assemblies aligned by maintaining correct spacing

• Disconnect power to the appliance before servicing
• Access the mounting area per your model's service instructions
• Replace with the same style and orientation to ensure proper fit and insulation
• Inspect surrounding hardware and replace any damaged fasteners or worn mounting surfaces

This small mounting screw secures panels and trim on compatible GE appliances, restoring a solid, vibration-free fit. Use it to replace a missing, stripped, or damaged fastener and keep parts aligned and secure. What it does:

• Fastens panels, trim, or small components to the appliance frame
• Replaces missing or damaged screws that cause loose or rattling parts
• Restores secure attachment when threads are stripped or worn
• Helps maintain proper alignment to prevent noise and component wear

• Use the correct screwdriver size to avoid stripping the head
• Tighten until snug; do not overtighten to prevent thread damage
• Disconnect power or move the appliance to a safe position when accessing internal panels
• Consider a replacement clip or insert as recommended by the manufacturer

This steam kit is the OEM steam generator assembly that supplies steam for steam-refresh and wrinkle-care cycles. It restores the appliance's ability to produce steam for improved fabric care and odor removal. What it does

• Heats and releases water as steam into the drum during steam cycles to help relax wrinkles and freshen clothes.
• Addresses weak or no-steam symptoms when the dryer runs steam cycles but garments remain untreated.
• Works with the appliance's control system to deliver steam only during designated cycle phases.
• Helps reduce the need for ironing by loosening fabric fibers during the cycle.

• One steam generator assembly (steam kit) as shown.

• Disconnect power before starting any repair to avoid shock or flooding.
• Suitable for technicians or experienced DIYers; follow the appliance service manual for disassembly and routing of water/steam lines.
• Inspect and replace any brittle or cracked tubing and seals to prevent leaks; test for proper steam delivery after installation.
• Do not operate the dryer with missing or damaged panels; ensure all connectors are secure.
