Parts for Bosch HGS3063UC/07: Cavity & Frame Parts

This back panel replaces the rear access cover on compatible dishwashers to protect internal components and keep the machine's back sealed. It restores a finished appearance and shields wiring, hoses, and controls from debris. What it does:

• Covers and protects the dishwasher's rear components, including wiring and connections
• Helps keep out dust, pests, and moisture that can damage internal parts
• Restores structural fit and reduces rattles or loose trim at the back
• Supports proper routing of hoses and wiring through factory openings

• One back panel

• Disconnect power and turn off the water supply before starting any work
• Remove lower access panels and fasteners to access the rear; keep all hardware for reinstallation
• Align tabs/slots and secure with the factory screws; avoid over-tightening to prevent cracking
• Watch for sharp edges; wear gloves and handle the panel carefully

This is a genuine replacement mounting screw that secures panels and components in compatible Bosch appliances. It restores proper fastening and helps eliminate rattles or loose parts for safe, quiet operation. What it does:

• Fastens panels, brackets or components to appliance chassis
• Replaces missing, stripped or corroded screws that cause loose parts or vibration
• Restores proper alignment where stripped or worn fasteners allowed movement
• Small hardware solution for repair jobs that require original-fit fasteners

• Use the correct-size driver to avoid stripping the screw head
• Tighten until snug; avoid over-tightening which can crack plastic or strip threads
• Disconnect power and follow appliance safety procedures before working on the unit
• If threads are damaged, replace both screw and any damaged insert or clip for a secure fit

This oven rack replaces a bent, worn, or missing rack to restore a safe, level surface for cookware. It slides into the oven's side rails so you can position dishes for even baking, roasting, and broiling.

• Provides a stable surface for pots, pans, and bakeware at standard rack positions
• Slides along the oven's support rails for easy loading and removal
• Helps maintain proper air circulation and consistent cooking results when positioned correctly
• Common symptoms: rack warped, rusted, missing, unstable, or difficult to slide

• Allow the oven to cool completely; disconnect power or shut off gas before servicing
• Remove the old rack, align the new rack with the side rails, and insert levelly until fully seated
• Verify orientation and placement per your owner's manual

This control panel is the exterior console piece that houses the dishwasher's buttons and display, restoring the appliance's user interface and appearance when the original panel is damaged or nonfunctional. What it does:

• Provides the touchpoints and bezel for push buttons and display indicators
• Restores a secure mounting surface for control electronics and user controls
• Helps resolve symptoms like cracked or warped front panel, loose buttons, or exposed electronics
• Replaces a worn or cosmetically damaged console to improve usability and appearance

• One control panel/console

• Disconnect power and water supply before beginning any repair
• Removal typically requires removing the inner door panel and disconnecting control harnesses; keep track of fasteners
• Handle sharp sheet-metal edges carefully and avoid stressing wiring or connectors

This socket is an electrical terminal that provides a secure connection between wiring and a component, restoring reliable power delivery and signal continuity. Use it to replace a worn or damaged connector for safer operation. What it does:

• Forms a stable electrical connection between a wire and the mating terminal or component.
• Prevents intermittent power, arcing, or loss of function caused by corroded or loose terminals.
• Helps restore operation of motors, controls, or sensors when the original connector is faulty.
• Maintains correct alignment and retention of the wiring harness under normal use.

• Disconnect power to the appliance before inspecting or replacing electrical connectors.
• Remove broken or corroded terminals and ensure mating parts are clean and dry before installing the new socket.
• Use appropriate crimping or insertion tools to secure the wire—do not force or over-bend the terminal.

This aeration panel is the vent cover that helps direct airflow and protect internal components from debris. It restores proper venting and appearance when the original panel is damaged or missing. What it does:

• Covers and protects the appliance vent opening to prevent debris from entering
• Directs airflow to support proper aeration and drying performance
• Helps maintain the appliance's exterior appearance by replacing a cracked or faded panel
• Reduce rattling or vibration caused by a loose or broken vent cover

• Disconnect power to the appliance before starting any repair.
• Access typically requires removing the outer door or control panel—use appropriate tools.
• Handle trim pieces carefully to avoid scratching or bending.

Temperature sensor that monitors the appliance's internal temperature and sends readings to the control board so it can maintain correct operating temperatures. Replacing a faulty sensor restores accurate temperature sensing and proper cycle control. What it does:

• Measures internal air/compartment temperature and provides a signal to the control board for temperature regulation.
• Helps the control system decide when to start or stop cooling/heating cycles.
• A failing sensor can cause temperature errors, uneven temperatures, or excessive run times.
• Matches OEM function for reliable temperature feedback in the appliance's control system.

• Disconnect power to the appliance before servicing to avoid electrical shock.
• Handle the sensor and connector gently; avoid pulling on wires or bending the sensing tip.
• After installation, restore power and confirm normal operation and correct temperature behavior.

This door lock latch assembly secures the dishwasher door during cycles so the machine can start and run safely. It replaces a worn or damaged latch to restore proper door closure and cycle operation. What it does:

• Locks the dishwasher door so the control can initiate and complete wash cycles
• Prevents the door from opening during operation, reducing leaks and interruptions
• Restores a failed or inconsistent door-latch mechanism that stops cycles from starting
• Works as the mechanical interface between the door and the washer cabinet

• One door lock latch assembly

• Disconnect power and water supply before beginning any repair
• Access typically requires removing the inner door panel; support the door to avoid damage
• Verify alignment and smooth operation of the latch after installation; replace any damaged screws or retainers
