Parts for Dcs WOU230SS-88493A: Chassis Assy Parts

This panel mounting transformer provides the low-voltage power source required by a range of control panels and user interfaces, restoring display and control electronics power when the transformer fails. What it does

• Converts incoming mains voltage to the low-voltage supply used by the appliance control panel.
• Supplies stable power so displays, LEDs, and touch/keypad circuits operate correctly.
• Common symptom: dark or unresponsive control/display even though the appliance has main power.
• Common symptom: intermittent control or reset of electronic functions tied to the panel power.

• One panel mounting transformer (single unit only).

• Disconnect all power to the appliance before starting work to avoid shock or injury.
• Removal typically requires accessing the control panel—retain screws and hardware for reassembly.
• Transfer any wire connectors or mounting clips from the old transformer; match wire colors/terminals exactly.

This power cable assembly supplies mains power to a range, providing a safe, intact connection between the appliance and household wiring. Replace a damaged or worn cord to restore reliable power delivery and reduce shock/fire risk. What it does:

• Carries line voltage from the household circuit to the range's internal wiring and controls
• Replaces frayed, cut, or heat-damaged cords that cause intermittent power or no-power symptoms
• Prevents loose or corroded connections that can cause arcing, sparking, or tripped breakers
• Restores a proper strain-relieved connection at the appliance inlet

• Disconnect power at the breaker and verify no voltage before beginning work
• Follow the appliance wiring diagram and secure all terminals with correct hardware and torque
• Use appropriate strain relief and grounding practices per local electrical code

A replacement panel hinge cover that hides and protects the door hinge area while restoring a finished appearance. Helps keep the hinge secure and prevents dirt buildup around the hinge and panel joint. What it does:

• Covers the door hinge area to protect the hinge mechanism and surrounding panel edge
• Restores a clean, finished look when an original cover is cracked, loose, or missing
• Helps prevent debris and moisture from collecting on the hinge assembly
• Reduces rubbing or contact between the hinge and the outer panel trim

• Disconnect power to the appliance before beginning work to avoid injury.
• Remove the door or access panel to reach the hinge area; retain fasteners for reuse.
• Install by aligning over the hinge and snapping or securing with the original screws; do not force or bend the cover.
• If any hinge hardware is damaged or loose, address that before reinstalling the cover.

A black cover duct that protects and conceals the appliance duct opening for a clean finished appearance. Replaces worn or damaged duct covers to help maintain proper airflow routing and appliance aesthetics. What it does:

• Covers and protects the duct opening to prevent debris from entering the duct path.
• Helps maintain correct airflow routing behind or beneath the appliance cabinet.
• Restores a finished, factory look to the appliance where the duct is exposed.
• Can reduce drafts and light infiltration around the duct opening when properly seated.

• One black cover duct.

• Designed to snap or screw into a dedicated duct opening—inspect mounting points before installing.
• Turn off and unplug the appliance or disconnect power at the breaker before accessing rear or lower panels.
• Use basic hand tools; avoid forcing the part into place to prevent cracking.
• If other duct or panel components are damaged, replace them to ensure a proper fit and seal.
