Parts for Ge AVX10ACS1: 03 - Section3 Parts

This small flat washer fits over a .344" shaft and provides spacing and load distribution to protect mating parts and fasteners. It's a simple replacement to restore correct clearances and reduce wear. What it does:

• Provides a corrosion-resistant bearing surface and even load distribution for bolts or shafts
• Maintains proper spacing to prevent rubbing or misalignment of moving parts
• Helps reduce vibration and noise caused by loose or worn hardware
• Prevents premature wear of mating components by spreading clamping force

• Disconnect power and water and follow all safety precautions before servicing the appliance
• Confirm correct orientation, size, and seating before tightening fasteners
• Do not over-tighten; snug to manufacturer torque specifications if available
• Inspect surrounding components (shaft, fastener, mating surfaces) and replace any damaged hardware

A small insulating cap that protects appliance electrical terminal nuts from accidental contact and shorts. Keeps wiring connections covered to reduce shock and prevent debris or moisture from reaching the terminal area. What it does:

• Covers and insulates a terminal nut to help prevent accidental electrical contact and shorting.
• Protects terminals from dust, moisture, and debris that can contribute to corrosion or poor connections.
• Helps maintain a safer service area around high-voltage terminals during normal use.
• Commonly used where a protective cap is needed on appliance terminal blocks or compressor connections.

• One terminal nut cover

• Only install when appliance power is fully disconnected at the breaker or unplugged.
• Fits over the terminal nut; push on until seated—no special tools typically required.
• Inspect terminal and fastener for damage or corrosion before covering; replace underlying hardware if compromised.
