Parts for Lg LRBCC1204S/00: Compressor Parts

This rear handle is a direct-replacement door handle that restores a secure grasp and smooth door operation. Durable molded construction matches the original fit to keep your refrigerator door aligned and easy to open. What it does:

• Replaces a cracked, broken or missing rear door handle to restore safe opening and closing
• Provides the mounting surface and grip for the refrigerator door latch and user access
• Helps prevent stress on door trim and fasteners caused by a damaged grip
• Matches OEM fit and attachment points for proper alignment

• One rear refrigerator door handle

• Includes the handle only; verify which fasteners or trim pieces are required for your model before installing
• Remove power to the appliance or open as recommended by the manufacturer before accessing door components
• Use proper tools to remove door trim/fasteners; take care not to over-tighten screws to avoid cracking the new handle

This rear handle is a direct-fit replacement that restores a secure grip for opening and closing the appliance door. It replaces a cracked, broken or loose rear handle so the door operates safely and comfortably. What it does:

• Provides a sturdy grip for opening and closing the appliance door
• Replaces visibly cracked, chipped or broken handle parts
• Stops wobbling or loose-feeling door handles that make the door hard to use
• Helps prevent further cabinet or door damage caused by a failing handle

• Disconnect power to the appliance before beginning any repair.
• Installation typically requires removing the door trim or access screws; use the correct screwdriver or nut driver.
• Keep all removed fasteners for reassembly and do not overtighten replacement screws.

This name plate is the exterior emblem that mounts to the appliance's front panel. It replaces a missing, cracked, or faded badge to restore a clean, factory look and cover the designated trim area.

• Attaches to the outer panel to display brand/series identification
• Restores a finished appearance where the original emblem sits
• Direct replacement for a lost, damaged, or worn badge
• Typical symptoms: missing emblem, loose or broken tabs, peeling, or discoloration

• Disconnect power before servicing the appliance
• Carefully remove the old emblem; release any tabs from behind or peel away remaining adhesive
• Clean and dry the mounting surface; remove all residue for best fit
• Align with the recess/holes and press evenly until fully seated

This hinge cover replaces the plastic trim that snaps over the top-lid hinge on compatible LG laundry units, restoring a finished appearance and protecting the hinge from dirt and snags. It helps keep the hinge area clean and reduces wear. What it does:

• Covers and protects the top-lid hinge from dust, lint, and incidental contact
• Restores the appliance's finished look by replacing cracked or missing trim
• Helps prevent clothing or small items from catching in the hinge gap
• Keeps hinge area cleaner to reduce buildup that can affect movement

• One hinge cover

• Disconnect power to the appliance before servicing to avoid electrical shock
• Typically snaps or screws into place after removing the top or locating hinge area; hold the lid when working to prevent it from falling
• Use basic hand tools; do not force parts—inspect mounting tabs for damage before installation

This overload protector is a direct-replacement electrical safety device that helps protect the compressor motor from overheating and overcurrent. It trips the circuit when the compressor draws excessive current, helping prevent damage and allowing normal operation once cooled. What it does:

• Detects excessive current or high temperature at the compressor and interrupts power to prevent motor damage.
• Helps stop hard-starting or repeated short-run cycles caused by motor overload.
• Commonly linked to symptoms such as a refrigerator or freezer that hums or clicks, runs briefly then stops, or fails to maintain proper cooling.
• Works with the start components to ensure reliable compressor startup and protect against electrical stress.

• Always unplug the appliance or disconnect power at the breaker before servicing.
• Handle compressor terminals and wiring carefully; avoid bending or damaging terminal tabs.
• Replace with the identical part number or OEM-specified protector to ensure correct fit and electrical ratings.
• After installation, restore power and observe the appliance through one full start/stop cycle to confirm normal operation.

This small stopper installs in the refrigerator to limit the travel of a moving component and keep it securely in place. Replacing a broken or missing stopper prevents over-extension and helps maintain smooth, aligned operation.

• Limits the range of motion for a door, bin, or drawer to prevent over-opening or accidental removal
• Helps keep interior components aligned and operating smoothly
• Replace if cracked, missing, or deformed
• Common symptoms: drawer or bin slides out too far, door swings past normal range, or a broken plastic stop is found

• Disconnect power before servicing; remove or support the affected bin/drawer/door
• Note the old stopper's orientation and location before removal
• Transfer and reuse any original screws or clips if applicable
• Snap or fasten the new stopper in place and test for smooth movement

The Drier Assembly is an OEM part for LG refrigerators. This part removes moisture and contaminants from the refrigerant, ensuring the system operates efficiently and effectively. The drier assembly helps maintain the proper function of the compressor and other cooling components, contributing to the longevity and performance of the refrigerator.

Causes of a bad drier assembly can include clogs from debris, wear and tear over time, or contamination from moisture or refrigerant leaks.

Symptoms of a bad drier assembly include:

• The refrigerator not cooling properly
• Frost or ice buildup on the evaporator coils
• Increased noise from the compressor
• Reduced efficiency and higher energy consumption
• You should replace the drier assembly if it becomes faulty or damaged.

This OEM LG part is also compatible with select Sears/Kenmore models.

The Fan Guide Assembly is an OEM component specifically designed for LG refrigerators equipped with rear evaporator fans. This assembly guides proper airflow within the refrigerator compartment.

Symptoms of a bad fan guide assembly include:

• Development of warm or cool spots inside fridge surfaces
• Excessive frost or moisture buildup at specific locations
• Reduced temperature fluctuation stability
• Abnormally loud fan operation sounds

Causes of failure can be damage allowing fan blade strikes, cracks reducing structural integrity over time, or accumulation of dust clogging air passages.

Replace yours today with this genuine OEM LG assembly to maintain optimized cooling throughout storage areas. Smooth, balanced airflow preserves food freshness evenly. This replacement part is compatible with Frigidaire, GE, and Samsung models for factory fit and function. Proper air distribution helps maintain energy efficiency.

This DC motor assembly replaces the appliance's original drive motor to restore reliable powered movement and control. It offers direct-fit replacement when the existing motor fails, helping stop failures or erratic operation. What it does

• Spins and controls the appliance's driven components using a DC motor drive.
• Restores normal operation when symptoms include failure to start, intermittent running, or loss of power to the driven system.
• Stops or reduces abnormal noises or vibration caused by a worn or damaged motor.
• Works with the appliance's control system to respond to speed and torque commands.

• One DC motor assembly.

• Disconnect power before beginning any repair to avoid shock or injury.
• Installation requires basic hand tools and may require removing panels or brackets for access.
• Keep mounting hardware and wiring orientation the same; reconnect all plugs securely.
• If you see damage to connectors or wiring, replace or repair those before powering the appliance.

The Ice Maker Assembly is an OEM replacement part for LG refrigerators. It contains the complete ice-making components including the ice tray, ejector mechanism, and fill tube.

Causes of a bad Ice Maker Assembly can include issues with proper ice ejection, ice cube size or shape inconsistencies, decreased ice production over time, mineral or sediment buildup affecting performance, or wear and tear from extended use.

Symptoms include:

• Incomplete or inconsistent ice filling of the ice tray
• Cracked, pitted, or misshapen ice cubes
• Ice cubes not ejecting from the tray properly
• Slowed or ceased ice production

This OEM LG ice maker assembly is also compatible with some Kenmore refrigerator models.

This mechanical mounting band secures a bracket assembly inside the appliance to keep components aligned and reduce vibration. It restores proper bracket positioning so moving parts run quietly and reliably. What it does:

• Holds a bracket or component assembly in place to maintain proper alignment
• Dampens movement and reduces vibration-related noise or rattling
• Prevents excess wear by keeping parts from shifting during operation
• Helps maintain correct clearances to avoid interference or rubbing

• Disconnect power before inspecting or replacing internal parts
• Remove only the fasteners necessary to access the bracket; keep track of hardware
• Secure all fasteners to the manufacturer's torque or snug specification
• Replace the band if bent, cracked, or missing to restore proper fit and function
