Parts for Ge AZ22E09E2BM1: 04 - Section4 Parts

This evaporator assembly circulates refrigerant and absorbs heat inside the freezer compartment to maintain proper cold temperatures. Replaces a damaged or corroded evaporator to restore normal cooling performance and reduce frost buildup. What it does

• Acts as the refrigerant coil where cold is produced for the freezer compartment
• Removes heat from the freezer air so the appliance can maintain set temperature
• Commonly replaced for excessive frost/ice, reduced cooling, or visible coil damage
• Works with the appliance's defrost system to prevent frost accumulation

• One evaporator assembly as shown

• Disconnect power before starting work; follow all safety precautions
• Access requires removing interior freezer panels; expect refrigerant-system connections to be present
• Handle evaporator fins carefully to avoid damage; check and replace any damaged gaskets or seals during reassembly

The Compressor Cushion is an OEM replacement part for GE refrigerators and air conditioners. It is designed to absorb vibrations and reduce noise generated by the compressor during operation. This cushion helps stabilize the compressor, ensuring smooth and quiet performance while protecting adjacent components from excessive wear.

Over time, compressor cushions can deteriorate due to heat, vibration, or regular wear and tear. A damaged or missing cushion may lead to increased noise, vibrations, and potential strain on the compressor and surrounding parts.

Symptoms of a bad or missing compressor cushion include:

• Excessive noise or vibrations during operation
• The compressor appearing loose or unstable
• Increased wear or damage to nearby components
• Reduced efficiency or uneven performance of the appliance

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
