Parts for Lg DLGX8601BE: Control Panel And Plate Assembly Parts

This frame assembly is the front trim piece that secures and finishes the appliance opening, restoring a flush, stable fit and the unit's finished appearance. Use it to replace cracked, warped, or missing front frame pieces. What it does:

• Provides the structural front trim that holds the door/glass and control area in correct alignment
• Restores a secure, gap-free fit and prevents rubbing or catching of moving parts
• Returns the appliance's finished appearance when the original frame is cracked, bent, or discolored
• Helps maintain proper spacing for seals and panels to reduce air leaks and debris entry

• One frame assembly

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Remove surrounding trim panels and any clips or screws holding the old frame; keep fasteners for re-use unless damaged
• Handle any attached glass or delicate trim carefully—support large pieces to avoid breakage
• Test fit before final assembly; tighten fasteners to secure fit without over-torquing

This PCB display assembly replaces the appliance's front display/control board to restore visible status indicators and panel control. It's used when the display is blank, unresponsive, or showing incorrect/error readouts. What it does:

• Powers and drives the front display so you can see cycle status, timers, and error codes
• Routes touchpad or button signals to the main control, enabling user input
• Can resolve symptoms like a blank or flickering display, non-responsive controls, or persistent display error messages
• Works as the interface between the user console and the appliance control system

• One PCB display assembly

• Disconnect power before starting to avoid shock or damage
• Handle the PCB by the edges and avoid touching components to prevent ESD damage
• You may need to remove the control console or top panel to access and replace the board; keep track of connectors and fasteners
