Parts for Ge JGBS23DEM7BB: 02 - Control Panel & Cooktop Parts

This end support secures and aligns the appliance drum/shaft assembly so the tub spins smoothly and quietly. Replacing a worn support restores proper drum position and reduces rubbing or wobbling during operation. What it does:

• Holds the drum/shaft in the correct position at the left front to maintain smooth rotation
• Provides a mounting surface and bearing area that prevents metal-on-metal contact
• Common symptom: loud scraping, grinding or thumping noises during spin
• Common symptom: visible drum wobble, rubbing or uneven rotation

• Disconnect power before any disassembly
• Remove outer panels and drum as needed to access the support; follow your model's service manual for steps
• Keep track of fasteners and note part orientation for correct reassembly
• Inspect adjacent parts for wear and replace if needed

End support cap for gas ranges. Installs on the side panel to provide structural support and a finished appearance. Replace if cracked or missing.

This right-side end support secures and aligns a refrigerator shelf/rail or drawer track so slides operate smoothly and stay in place. Replacing a damaged support restores proper shelf alignment and prevents drawers or bins from sagging. What it does

• Holds the end of a shelf rail or drawer track to keep sliding parts aligned
• Prevents shelves or drawers from sagging, binding, or falling out
• Reduces wobble or uneven movement when loading or sliding shelves/drawers
• Helps restore proper operation after a cracked, broken, or worn end bracket

• Disconnect power before working inside the refrigerator and remove food/items from affected area
• Remove the shelf, drawer, or rail to access the end support; note orientation for reassembly
• Require basic hand tools (screwdriver, nut driver) and light prying to release tabs or fasteners
• Reinstall components and test sliding action; discard damaged parts before reuse

Right end support cap for gas ranges. Secures and covers the side panel edge. Replace if cracked, broken, or missing to restore a finished appearance.

Right hand side

Left hand side

Color: White

Replace your worn, cracked, or missing range control panel touch pad. This cosmetic trim piece covers the control area for a finished look.

Upper back cover panel for gas ranges. Replaces cracked, damaged, or missing housing cover on the rear upper section. Restores appearance and protects.

Replace the lower back cover panel on your gas range. This housing protects internal components and maintains structural integrity when cracked or damaged.

Secures components to your appliance chassis for a rattle-free fit. Replace missing, stripped, or corroded screws to keep panels and brackets aligned.

Includes 12 speed nuts.

Burner won't light or no ticking sound from igniters? This spark module generates the spark that ignites gas burners. Moderate DIY repair, 30-45 minutes.

Gas range not igniting or clicking continuously? This electrode and harness assembly restores proper spark ignition. Common repair for burners that won't light.

Gray cast iron burner grate for gas ranges. Replaces cracked, broken, or worn grates. Measures 8.5" x 8.5". Sold individually, not as a set.

Burner grate for gas ranges. Holds cookware over burners. Replace if cracked, warped, rusted, or missing. Sold individually, not as a set.

Pivot pin that connects the oven door hinge to its mounting bracket. Replace if worn, broken, or missing to restore smooth door operation and alignment.

Screw and washer assembly for securing cooktop and internal range components. Replace if missing, rusted, stripped, or damaged during appliance repair.

Factory screw secures brackets, panels, trim, or burner components on ranges, cooktops, and wall ovens. Replaces missing, stripped, or corroded fasteners.

Secures cooktop panels, brackets, and components on your gas range. Replace missing, stripped, or damaged screws to eliminate rattles and restore alignment.

Gray left-side drip pan for gas ranges. Replaces cracked, rusted, or stained original pans. Sits beneath burner to catch spills and protect cooktop surface.

Double drip pan installs beneath range burners to catch spills and cooking residue. Replace when cracked, stained, or coated with burnt-on grease.

Double drip pan installs under two burners on your gas range to catch spills and debris. Replace if cracked, corroded, rusted, or discolored.

Replace cracked, stained, or worn drip pans that sit beneath burner elements. Catches spills and crumbs during cooking. Easy cosmetic upgrade.

Black touch pad overlay for range control panel. Replaces worn, faded, or cracked overlays. Installs over existing control board for a refreshed appearance.

Replacement control panel overlay for your range. Covers the control board with printed labels and buttons. Needed when original is cracked, cut, or worn.

Replaces chipped, cracked, or missing burner cap on your gas range cooktop. This grey cap sits atop the burner base to direct and shape the flame properly.

Black burner cap sits on top of your gas range burner head. Replace if cracked, chipped, stained, or missing to restore your cooktop's appearance.

Grey medium burner cap for gas ranges and cooktops, 3 inches in diameter. Replaces chipped, cracked, worn, or missing caps to restore appearance.

Black burner cap sits atop the burner head on gas ranges and cooktops. Replace if cracked, chipped, discolored, or missing to restore appearance.

Grey burner cap for gas range cooktops. Measures 3-1/2 inches diameter. Replace chipped, worn, cracked, or missing burner caps for a complete look.

Black burner cap for gas range cooktops. Replaces cracked, stained, warped, or missing caps. Sits atop burner base for proper flame distribution.

Replacement small surface burner for gas ranges and cooktops. Installs on stovetop to provide heat for smaller pots. Replace if damaged, discolored, or missing.

Replace your cracked, warped, or missing medium surface burner. Ensures even heat distribution for cooking tasks. Installs on gas range cooktops.

Burner base holds and secures the gas burner assembly on your cooktop. Replace if cracked, warped, or corroded to restore proper burner seating.

Secures the ignition electrode on gas range burners. Replace if burners won't spark, igniter clicks continuously, or clip is corroded or loose. Confirm fit with your model number.

Color: White. Mounting screw for end caps.

Mounting screw for range installation and assembly. Replace missing, stripped, or damaged screws to secure panels, brackets, or components properly.

Replacement mounting screw secures panels, brackets, and trim on ranges and cooktops. Install to replace missing, stripped, or rusted fasteners.

Hex washer head screw for electric ranges. Secures panels, brackets, and internal components. Replace if screw is stripped, missing, or damaged.
