Parts for Bosch HBN646AUC/01: Control Panel Parts

This replacement door frame restores the dishwasher door's outer trim and supports attached panels and hardware for a finished appearance. It helps secure the door assembly and keeps internal components aligned for normal operation. What it does:

• Replaces a damaged, dented, or bent door trim to improve looks and door fit
• Provides a mounting surface for clamps, seals, and exterior panels
• Helps maintain proper door alignment to reduce leaks and closing issues
• Restores the structural edge that protects internal components from damage

• One door frame (trim) as pictured

• Disconnect power and water supply before starting any repair
• Remove the door panel and any attached hardware to access the frame; retain fasteners for reassembly
• Reinstall panels and verify door alignment and seal before restoring service

Circuit board spacer for wall ovens. Maintains proper spacing between electronic control boards. Replace if broken, cracked, or missing to prevent board damage.

This selector switch allows you to choose different cooking modes for your convection oven including bake, broil, convection bake, and other specialized functions. It directs power to the appropriate heating elements and activates the convection fan when needed. Replace this switch if you can't select certain cooking modes, if the oven operates in the wrong mode, or if the switch feels loose or unresponsive.

Protective sleeve for wall ovens. Shields internal components from heat and damage. Replace if cracked, melted, or missing to maintain oven safety.

Red indicator light for wall ovens signals heating status. Replace when light fails to illuminate or stays on constantly. Verify compatibility with your model.

M4.2 x 9.5mm mounting screw for wall ovens. Secures interior panels, brackets, and components. Replace if stripped, missing, or damaged during repairs.
