Parts for Bosch WTB86200UC/07: Control Panel Parts

This coupling connects the dishwasher motor to the wash pump so the motor can drive the impeller for normal water circulation. Replacing a worn coupling restores drive between motor and pump and helps the dishwasher pump water effectively. What it does:

• Transfers rotational force from the motor to the pump impeller for wash and drain cycles
• Prevents slipping when the motor runs, ensuring consistent water circulation
• Commonly replaced when the motor runs but the pump doesn't turn or performance is reduced
• Can help stop grinding, clunking, or unusual noises coming from the pump area

• Disconnect power to the appliance before any service to avoid shock or injury
• Access usually requires removing the access panel and/or pump housing—follow OEM service instructions
• Inspect the surrounding seals and pump components when replacing the coupling; replace any damaged parts

The Power Cord is an OEM part for Bosch electric dryers. It provides power to heating elements and motor components, enabling all dryer functions. Working seamlessly behind wall panels and the control board, the cable supply facilitates safe and reliable drying performance cycle after cycle.

Symptoms of a bad power cord include:

• The dryer fails to power on or heat
• Flickering lights or control issues
• Burning smells coming from internal areas
• Cable sheathing showing defects or damage

Causes for failure relate to insulation breaks, fraying, or cuts to wiring over time. Accidental impact, animal/insect damage, or general wear and tear may also degrade cable supply integrity.

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This facia panel is the outer trim for the appliance control area, restoring the appliance's finished look and protecting the underlying controls. It replaces damaged, cracked, or worn front trim for a clean, factory appearance. What it does:

• Covers and protects the control assembly and buttons from dirt, moisture, and everyday wear
• Restores a finished, attractive look when the original facia is cracked, warped, or scratched
• Helps keep control buttons and indicators aligned and accessible
• Prevents debris from entering the control area, reducing the chance of button sticking or cosmetic failure

• High-level replacement only; remove power to the appliance before starting
• May require removal of door or console trim panels and use of basic hand tools
• Handle panel carefully to avoid damage to clips or paint/finish during installation

This operating module is the dishwasher user control board that receives button presses and runs the appliance's cycle logic, restoring normal panel operation and cycle selection when the original control fails. What it does

• Interprets touchpad/button inputs and manages start/pause commands
• Controls cycle selection, timers, and display indicators
• Communicates with the main electronic systems to start and stop wash cycles
• Stop responsive panel behavior, cause unresponsive buttons, or prevent cycle initiation when failing

• Disconnect power to the appliance before removing panels or replacing the module
• Handle the board by its edges and avoid static discharge; use an anti-static strap if available
• You may need to remove the control panel or console trim to access the module
