Parts for Kenmore 790.47889602 (79047889602, 790 47889602): Control Panel Parts

Technical service data sheet for wall ovens. Provides wiring diagrams, component locations, and troubleshooting information for repair technicians.

This parts list is the printed diagram and parts index used to identify service items for the appliance. It makes finding the correct replacement components faster and reduces ordering errors during repairs. What it does:

• Shows the exploded diagram and index mapping part numbers to locations
• Helps identify which component corresponds to a specific symptom or failure
• Speeds up parts ordering by listing exact part numbers and descriptions
• Useful for techs and DIYers to needed replacements before disassembly

• No mechanical installation required; keep with your owner's manual or service documentation
• Handle the sheet carefully to avoid tearing or losing small reference numbers
• Replace only if lost, unreadable, or damaged; store in a dry place
• Not an electrical or functional component—use for identification and ordering only

Replacement instruction sheet for your wall oven. Includes operating guidelines and care information. Ideal if your original manual is lost or damaged.

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation
