Parts for Magic Chef CYG3004AWW: 02 - Control Panel Parts

This resistor assembly reduces voltage in the motor/blower circuit to provide lower speed settings on compatible appliances. A failed resistor commonly results in loss of one or more speeds or the fan/blower running only on high. What it does:

• Drops voltage to create low/medium speed settings where designed
• Helps the speed switch deliver distinct fan/motor speeds
• Resolve issues like only high speed working
• Address no low/medium speeds or inconsistent speed changes

• 1 resistor assembly

• Disconnect power before servicing and verify no voltage is present
• Mount in the original location/orientation to ensure proper cooling airflow
• Move wires one at a time to avoid miswiring
• Inspect and replace any heat-damaged connectors or wiring as needed

The Timer is an OEM part for Whirlpool dryers. It controls the electrical components and the timing of the drying cycles, ensuring clothes are dried according to the selected settings. This timer manages the duration of each cycle, turning the dryer off when the cycle is complete.

Over time, the timer can fail due to wear and tear, electrical malfunctions, or internal component damage.

Symptoms of a bad timer include:

• The dryer not advancing through cycles
• The dryer running for an unusually long time
• The dryer not turning on or off at the appropriate times
• Irregular or incomplete drying cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
