Parts for Lg DLEY1701V: Control Panel Parts

This top plate assembly replaces the cooktop surface that sits above the range's burner box, restoring a secure, finished surface and helping keep internal components protected from spills and debris. What it does:

• Provides the finished cooktop surface and support for burner components
• Protects internal wiring and components from spills, crumbs and heat exposure
• Restores proper fit and alignment when the original top is dented, cracked or warped
• Helps maintain a clean, even appearance and safe cooking surface

• Disconnect power (and gas supply for gas ranges) before starting any repair.
• Handle edges and painted surfaces carefully to avoid cuts and cosmetic damage.
• Replacement may require removing burners, grates or control panel for access; keep fasteners organized.

This display power control board assembly powers and controls the appliance's front display and touch/press controls, restoring visible readouts and responsive control input for the user interface. Installs behind the control panel. What it does:

• Supplies power to and drives the front display LEDs/LCD and associated lights.
• Interfaces between the user control buttons/touchpad and the main control board.
• Common replacement for blank or dim displays, unresponsive controls, or intermittent display behavior.
• Can resolve error-code display failures or missing status indicators tied to the display board.

• Disconnect power to the appliance before starting any work to avoid shock or damage.
• Handle the circuit board by its edges and avoid touching components; observe ESD precautions.
• Reconnect all wire harnesses and mounting hardware securely; confirm display cables are seated.

This main control board is the appliance's central electronics module, also called the main PCB assembly. It manages power and coordinates sensors and user commands so the unit runs correctly, restoring normal operation when the original board fails. What it does

• Controls and coordinates motors, fans, valves, and other components based on inputs
• Processes signals from sensors and the user interface to execute functions
• Manages timing and safety interlocks for reliable operation
• Common symptoms of a failed board: unit won't power on/start, unresponsive or erratic controls/display, intermittent shutdowns, or error codes

• One main PCB assembly

• Disconnect power to the appliance before servicing; avoid ESD by handling the board by the edges and using grounding protection
• Move connectors one at a time to matching positions; transfer any brackets, covers, or jumpers from the original board
• Ensure all plugs are fully seated and the board is mounted securely
• Some models require a control reset or service test after installation—follow the service manual for your model

This safety cover is an internal protective shield used inside the dryer to guard components and help maintain proper airflow. Replacing a cracked or missing cover helps keep wiring and moving parts enclosed for safer operation. What it does:

• Shields internal wiring and components from accidental contact
• Helps channel air and lint flow as designed
• Replaces a damaged, heat-warped, or missing cover
• Helps resolve rattling/vibration noises and visible gaps where the cover mounts

• Includes 1 safety cover

• Unplug the dryer; for gas models, shut off gas and allow the unit to cool
• Access the cover location per your model's service manual; remove panels as needed
• Position the cover correctly and secure using existing hardware/clips
• Do not operate the dryer with the cover removed or loose
