Parts for Lg DLEY1701VE: Control Panel Parts

This top plate assembly replaces the cooktop surface that sits above the range's burner box, restoring a secure, finished surface and helping keep internal components protected from spills and debris. What it does:

• Provides the finished cooktop surface and support for burner components
• Protects internal wiring and components from spills, crumbs and heat exposure
• Restores proper fit and alignment when the original top is dented, cracked or warped
• Helps maintain a clean, even appearance and safe cooking surface

• Disconnect power (and gas supply for gas ranges) before starting any repair.
• Handle edges and painted surfaces carefully to avoid cuts and cosmetic damage.
• Replacement may require removing burners, grates or control panel for access; keep fasteners organized.

This display power control board assembly powers and controls the appliance's front display and touch interface so your cycles display information and buttons respond. It restores display illumination and control communication when the board has failed. What it does:

• Provides power and signal control for the front display and touchpad
• Restores display illumination and readable cycle/status indicators
• Re-establishes communication between user controls and main control board
• Commonly replaces a board when the display is blank, unresponsive, flickering, or shows incorrect information

• Disconnect power to the appliance before starting and verify power is off.
• Handle the board by the edges and avoid static discharge; wear an anti-static wrist strap if available.
• Inspect connectors and ribbon cables for damage; confirm all connectors seat fully during reassembly.

The Main PCB Assembly is an OEM part for LG dryers. It contains the central processing unit that manages all core functions of the dryer through electronic components and programming. The main PCB controls operations like temperature selection, timer settings, drum rotation, heating element activation, and more.

Symptoms of a bad main PCB assembly can include the dryer failing to start, not detecting temperature settings, inability to advance through cycles or inconsistent or abnormal functioning.

Causes of a bad main PCB include water damage, thermal overloads from continued usage, defective soldering or wiring, and normal component degradation.

Symptoms of a bad main PCB assembly include:

• Dryer not powering on
• Timer not counting down properly
• Abnormal sounds coming from motor or heating elements
• Temperature presets not registering
• Cycles not completing

This OEM LG part is also compatible with Sears/Kenmore.


This safety cover is an internal protective shield used inside the dryer to guard components and help maintain proper airflow. Replacing a cracked or missing cover helps keep wiring and moving parts enclosed for safer operation. What it does:

• Shields internal wiring and components from accidental contact
• Helps channel air and lint flow as designed
• Replaces a damaged, heat-warped, or missing cover
• Helps resolve rattling/vibration noises and visible gaps where the cover mounts

• Includes 1 safety cover

• Unplug the dryer; for gas models, shut off gas and allow the unit to cool
• Access the cover location per your model's service manual; remove panels as needed
• Position the cover correctly and secure using existing hardware/clips
• Do not operate the dryer with the cover removed or loose
