Parts for Maytag MHW3500FW1: 04 - Control Panel Parts

This console is the exterior control panel assembly that houses the oven/range controls and display, restoring a clean surface and functional buttons. It provides the user interface for setting bake, broil, timers and other cooking functions. What it does:

• Replaces a cracked, damaged or cosmetically worn control panel so buttons and displays are accessible
• Restores tactile response for touchpads and mechanical buttons
• Helps correct symptoms like unresponsive controls, missing display segments or loose panels
• Supports secure mounting of control electronics and user interface components

• Disconnect power before starting any repair
• Handle the console carefully to avoid damaging the display, wiring or trim
• Some installations require removing screws, trim pieces or the back guard to access mounting points
• If the console contains attached wiring harnesses, disconnect connectors gently and note their locations for reassembly

The Handle is an OEM replacement part for Whirlpool washers that allows you to easily open and close the dispenser drawer on your washer. It provides a comfortable and secure grip, ensuring easy access to the detergent and fabric softener compartments.

Symptoms of a bad dispenser drawer handle include:

• Cracked or broken handle
• Difficulty in opening or closing the dispenser drawer
• Loose or unstable handle grip

A worn-out or damaged dispenser drawer handle can occur due to regular use or accidental mishandling. If you notice cracks, breaks, or difficulty in opening or closing the dispenser drawer, it may be time to replace the handle.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.


This control knob attaches to the appliance's control shaft so you can select settings with a solid, positive feel. Replace a cracked, stripped, or missing knob to restore smooth operation and a clean, finished look.

• Attaches to a switch or valve shaft to select temperatures, burner levels, or cycles
• Transfers your hand turn to the control shaft for accurate setting changes
• Common symptoms: cracked hub, spins without engaging, wobbly/loose, falls off, or missing
• Helps maintain a uniform appearance across the control panel

• Disconnect power (and shut off gas, if applicable) before servicing
• Pull the old knob straight off the shaft; avoid prying against the control panel
• Align the insert with the shaft's flats or splines and press straight on until fully seated
• Match position- and finish-specific knobs to the original on models that use different knobs per location

This wire harness routes power and signal connections between an appliance's controls and components, restoring proper electrical continuity for normal operation. It replaces a damaged or worn harness to help resolve power and control issues. What it does:

• Provides the factory wiring connections between control boards, motors, and sensors
• Restores reliable power and signal paths when wiring is frayed, melted, or broken
• Can stop intermittent operation, failure to start, or control communication errors when caused by wiring faults
• Keeps wires organized and secured to prevent chafing and short circuits

• One complete wire harness as shown

• Disconnect all power (unplug or shut off breaker) before beginning work
• Transfer and align connectors exactly as removed; do not force mismatched plugs
• Route and secure the harness with existing clips or fasteners to avoid contact with hot or moving parts

This is a replacement screw designed to work with a wide range of household appliances. It is used for many purposes in these appliances, from holding body panels together to securing electronics into control boards. However, screws are subject to damage through corrosion, impact, and improper installation/removal. In most cases, the primary damage to this screw is through corrosion – it may become rusted or corroded in place, depending on the appliance and the maintenance provided during its lifespan. The screw may also be stripped or rounded due to improper removal or installation. If the screw is damaged, lost, or corroded in place, it will need to be replaced. In most cases, removal will require nothing more than a Phillips head screwdriver or the appropriately sized socket with a ratchet. However, if the screw is damaged, it may require a tap set to remove it from its mounting location. Note that this is a genuine OEM replacement screw made from durable, high-quality metal, and is sold individually. It fits Whirlpool, Maytag, Roper, Estate, Amana, Crosley, and Thermador appliances. It is used in over 150 machines, ranging from washers and dryers to air conditioners.

This wire harness routes power and signals between an appliance's control and internal components to restore reliable electrical connections. Replacing a damaged harness helps stop intermittent operation and power loss for safer, more consistent performance. What it does:

• Routes power and control signals between the control board and internal components.
• Replaces frayed, cut, or burned wiring that can cause intermittent operation or component failures.
• Helps address symptoms such as loss of power to controls, unresponsive cycles, or devices that won't start.
• Prevents loose or corroded connections that can create intermittent faults.

• Always disconnect the appliance from power (unplug or switch off circuit breaker) before servicing.
• Match each connector to its mating plug and follow the OEM wiring diagram for routing and color codes.
• Secure the harness away from heat sources and moving parts; use existing clips and fasteners.
