Parts for Whirlpool WMH32519HT2: Control Panel Parts

This control panel is the oven console assembly that houses the touchpad, display, and controls so you can set bake/temperature functions and timer features. It restores user input and visible status feedback on the range/oven. What it does:

• Provides the user interface for selecting bake, broil, timer and other oven functions
• Transmits button and touchpad commands to the oven control board
• Displays temperature, time and error codes on the console display
• Common symptom fixes: unresponsive buttons, blank or garbled display, or inability to start oven functions

• Disconnect power at the breaker before beginning any repair to avoid shock.
• Handle with care to avoid damage to the display or ribbon/connector cables.
• Follow OEM disassembly steps: remove backguard/console fasteners, disconnect wiring harness, swap the panel, then reconnect and test.

This control panel is the front console assembly that lets you operate your range/oven and view status. It restores button and display control so you can set cook modes, temperatures, timers, and clock functions. What it does:

• Provides the touchpad/buttons and display area used to select oven functions, temperature and timers
• Sends user inputs to the oven control so bake, broil, self-clean and timer commands register
• Replaces panels that have cracked buttons, faded labeling, or an unresponsive touchpad
• Can resolve display/backlight issues or intermittent command loss linked to a damaged console

• Disconnect power at the breaker before removing the old console to avoid shock
• Handle carefully to avoid scratching the finish or damaging attached wiring/contacts
• May require removing trim screws and unplugging a wire harness; save fasteners for reassembly

Note: In some cases the original board had a wire harness connection at P9 for an NTC thermistor. The newly designed board has the NTC thermistor built into the board and the wiring connection is no longer required.

This electronic control board replaces the main console control for electric ovens and ranges, restoring responsive controls and timed cooking functions. It manages user inputs, display output, and cycle sequencing for the appliance. What it does:

• Receives commands from the touchpad/knobs and drives oven heating cycles and timers
• Controls display and indicator lights so settings and temperatures are visible
• Manages oven bake/clean modes and safety interlocks during operation
• Commonly used when the oven won't heat, displays are blank or show errors, or controls are unresponsive

• One electronic control board

• Disconnect power to the appliance before starting any repairs to avoid shock
• Handle the board by its edges and avoid touching components; wear anti-static protection if available
• Some models require removing the control panel or console to access the board; keep screws and connectors organized
