Parts for Jenn-Air SEG196: 07 - Control Panel Parts

This mounting set is the installation hardware used to secure the appliance to surrounding cabinetry or framing, helping keep the unit stable and properly aligned during use. What it does

• Provides the bracketry and fasteners needed to anchor the appliance in place
• Prevents the appliance from shifting, tilting, or vibrating during operation
• Helps maintain a consistent fit and gap to adjacent cabinets or countertops
• Reduces rattling and movement-related wear on hoses and connections

• Disconnect power and turn off water before starting installation
• Use the OEM instructions for correct fastener locations and torque; do not overtighten
• Verify the appliance is level and properly supported while securing the mounting set

This valve knob replaces a worn or broken control on a gas range or cooktop. It attaches to the burner valve shaft so you can turn the burner on/off and adjust the flame with smooth, reliable control.

• Couples to the surface burner valve shaft to select Off/High/Low and regulate flame
• Restores control when the original knob is cracked, stripped, loose, or missing
• Provides a secure grip and proper alignment with panel markings for accurate settings

• Turn all controls to Off and let the surface cool before starting; disconnect power if working near igniters
• Pull the old knob straight off the valve shaft—do not pry sideways
• Align the flat/D-shaped opening with the shaft and press straight on until fully seated; verify the Off position aligns with the panel
• If the knob does not seat easily, stop and recheck the part number and shaft style

This replacement screw fastens appliance panels and components to restore secure mounting and stop rattling or loose parts. A basic, direct-fit fastener for routine repairs and reassembly. What it does:

• Secures panels, brackets, trim, or internal components to prevent movement and vibration
• Replaces missing or stripped screws that cause loose parts or rattling noises
• Restores reliable fastener retention for safe, stable operation
• Works wherever the OEM-specified screw is required for proper assembly

• Use the matching driver/socket and turn slowly to avoid stripping the head or threads
• Tighten until snug; do not over-torque to prevent damage to threads or housings
• Power off and unplug the appliance before attempting any repair
• If other fasteners or damaged mating threads are found, inspect surrounding components and replace as needed

To order indicator lens use WP22001948.

The Range Clock Knob is an OEM part for Whirlpool ranges. It attaches to the center of the oven control panel and allows users to adjust the built-in clock, serving as the primary control for setting or correcting the time.

Over time, the clock knob can become faulty due to regular use leading to internal stripping or wear, exposure to heat causing cracks or warping, or accidental impacts damaging the knob.

Color: Black

Symptoms of a defective range clock knob include:

• Difficulty setting or adjusting the clock
• The knob spins freely without engaging the control shaft
• The knob feels loose, cracked, or broken

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore ranges.

The Range Clock Knob is an OEM part for Whirlpool ranges. It attaches to the center of the oven control panel and allows users to adjust the built-in clock, serving as the primary control for setting or correcting the time.

Over time, the clock knob can become faulty due to regular use leading to internal stripping or wear, exposure to heat causing cracks or warping, or accidental impacts damaging the knob.

Color: Black

Symptoms of a defective range clock knob include:

• Difficulty setting or adjusting the clock
• The knob spins freely without engaging the control shaft
• The knob feels loose, cracked, or broken

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore ranges.

This part has been discontinued and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

This top burner valve switch mounts to a surface burner gas valve and closes the ignition circuit when you turn the knob to Lite. Replacing a worn switch restores dependable sparking and stops intermittent or nonstop clicking at the burners.

• Mounts on the surface burner valve and closes the ignition circuit at the Lite position
• Signals the spark module to fire the igniters so the burner lights
• Helps ensure quick, consistent burner ignition
• Common symptoms: no spark at a burner, intermittent ignition, or continuous clicking with knobs in Off

• Disconnect power and shut off the gas supply before servicing
• Pull off the burner knob and remove the control/manifold panel to access the valve switch
• Transfer wires one at a time and align the switch correctly on the valve stem; avoid overtightening
• Reassemble, restore power, test for spark with gas off, then relight and check for leaks

This gas valve controls the flow of gas to a burner, enabling safe ignition and precise flame adjustment. Replacing a worn valve restores smooth knob operation and consistent flame performance on your gas cooking appliance.

• Opens and closes to start/stop gas flow to a specific burner
• Works with the control knob to modulate flame size
• Helpful when a burner won't light despite spark/ignition present
• Can address issues like inconsistent flame or a knob that's hard to turn

• Disconnect power and shut off the gas supply before servicing
• Match the orientation and connections to the original valve
• Use an approved gas-rated thread sealant on threaded fittings
• After installation, check all joints for leaks with a soap-and-water solution

Replacement igniter switch that restores spark ignition for gas cooktops and ranges, helping burners light reliably and reducing intermittent or no-ignite symptoms. Designed as a like-for-like control component when your original switch fails. What it does:

• Sends the electrical spark signal to the burner ignition circuit so the burner lights
• Stops clicking or sparking when the switch fails, which can cause burners not to ignite
• Addresses symptoms like intermittent ignition, continuous clicking without flame, or no spark from the burner electrode
• Works as the control point between user knob/ignition module and the spark system

• Turn off power to the appliance and shut off the gas supply before servicing
• Replace with the exact part number and match connector types; do not force-fit a non-matching switch
• After installation, test burners for proper ignition and check for gas leaks before normal use

This LP conversion kit adapts compatible gas appliances from natural gas to liquid propane. Proper conversion helps ensure safe ignition, correct flame size, and consistent heating when your installation uses propane instead of natural gas. What it does:

• Converts the appliance's gas system from natural gas to LP/propane
• Matches burner/orifice sizing and regulator setting to propane fuel characteristics
• Helps correct symptoms tied to the wrong fuel: tall yellow flames, sooting, weak heat, uneven burner performance
• Required when connecting the appliance to an LP/propane supply

• Includes LP conversion kit

• Must be installed by a gas technician; follow local codes and the model-specific instructions
• Shut off gas and power before starting; verify all connections are leak-free with an approved leak-detection solution
• Replace the specified orifices and set/convert the pressure regulator to LP as directed; apply the provided LP identification label
• After conversion, verify flame appearance and manifold pressure
