Parts for Ge PTS9200SN1SS: Control Panel & Upper Door Parts

This RJ45 mounting bracket secures an RJ45 network/communication jack to the appliance frame, restoring proper connector alignment and mechanical support. It's a simple replacement part for damaged or missing brackets. What it does:

• Holds the RJ45 jack firmly in place to prevent connector movement and intermittent connections
• Aligns the jack for easy cable insertion and secure mating
• Protects the connector and wiring from strain or damage during use
• Helps restore reliable network/communication port positioning after panel or bracket damage

• One RJ45 mounting bracket

• Unplug the appliance or disconnect power before servicing
• Remove the access panel or trim to reach the existing bracket; retain fasteners for reassembly
• Gently disconnect the jack/cable before removing the old bracket; avoid pulling on wires
• Hand-tighten or torque screws to manufacturer specifications; do not overtighten

A small replacement spring wiper that restores proper contact pressure and wiping action on the appliance component it services. Replaces a worn or broken wiper spring to help maintain consistent performance and reliable operation. What it does:

• Provides tension and a wiping contact surface where the original spring wiper has worn or failed
• Restores consistent electrical/contact or mechanical wiping action that can affect operation
• Commonly replaced when loose, bent, broken, or when intermittent contact is observed
• Helps prevent arcing, poor contact, or inconsistent component movement when functioning correctly

• One spring wiper

• Evaluate the surrounding components and match before installing; replace only the part(s) explicitly specified
• Use proper tools and avoid bending or overstretching the spring during installation
• Disconnect power to the appliance before accessing or replacing electrical/contact components

This slider assembly base supports and guides a refrigerator/freezer drawer so it opens and closes smoothly. It replaces worn or broken slider bases to restore proper drawer alignment and movement. What it does:

• Provides the base support for the drawer slide mechanism to ensure smooth opening and closing
• Replaces cracked, broken or worn plastic slider components that cause sticking or uneven travel
• Helps prevent the drawer from falling out or binding during use
• Works with the existing slide/rail hardware to maintain proper alignment

• Disconnect power or remove food and follow manufacturer safety instructions before working in the appliance
• Remove the drawer and any trim to access the slider area; installation typically involves snapping or fastening the slider into place
• Inspect mating slide/rail components and replace any damaged clips or screws for a secure fit

Upper window pack assembly that replaces a cracked or damaged refrigerator door window panel, restoring appearance and helping protect the components behind the outer window. What it does:

• Replaces the upper door window pack to restore a clear, finished exterior on the appliance door.
• Addresses visible damage symptoms such as cracked, scratched, cloudy or broken window panels.
• Protects internal door components from exposure to moisture and debris.
• Matches the OEM-style mounting points for a like-for-like replacement when used with the correct model parts.

• Disconnect power and remove food from the door area before starting any repair.
• Handle the window pack carefully; wear cut-resistant gloves and eye protection when removing broken or cracked pieces.
• Remove any trim or fasteners per the appliance's service instructions; retain mounting screws and gaskets as needed.
• Refer to the OEM service manual or diagram for model-specific removal and reassembly steps.

A single mounting screw used to secure panels and components on compatible GE appliances. This genuine-fit fastener keeps parts firmly attached so panels and assemblies stay aligned and function safely. What it does:

• Secures trim, panels, brackets, or small components in place
• Restores loose or rattling panels caused by missing or stripped screws
• Helps maintain proper alignment of service panels and assemblies
• Prevents vibration-related noise from unsecured parts

• Use the correct size screwdriver or bit to avoid stripping the head
• Hand-start threads, then tighten securely but avoid overtightening to prevent damage
• If working near electrical components, disconnect power before servicing
• If a screw was stripped or the mounting hole is damaged, replace with the correct fastener size

This hex-head machine screw has a 10-32 thread and measures 1-3/4 inches long. Use it to replace a missing, stripped, or rusted fastener and restore a secure fit where this exact size is specified.

• Secures brackets, panels, and internal components requiring a 10-32 x 1-3/4 in hex-head screw
• Restores proper alignment and mounting integrity
• Replaces damaged, corroded, or lost hardware
• Can help resolve symptoms like loose/rattling parts or shifting components

• Disconnect power (and shut off gas, if applicable) before servicing; allow appliance to cool
• Remove the old screw, align parts, and start the new screw by hand to avoid cross-threading
• Tighten snugly but do not overtighten
• Reuse any original washers or spacers if present

This silicon controlled rectifier (SCR) is an electronic switching component that controls current flow in appliance control circuits, helping regulate power to heaters, motors, or other loads for stable operation. What it does:

• Switches and regulates current in control boards and power circuits
• Can prevent power from reaching a heater, motor, or element when failed
• Helps protect downstream components by controlling surge/current flow

• Disconnect power to the appliance before servicing to avoid shock.
• Handle the SCR carefully to avoid electrostatic discharge (ESD) damage.
• May require board-level replacement or soldering skills.
