Parts for Ge AZ41E09DABW3: 02 - Control Parts

This terminal board provides a secure electrical connection point for the appliance's main power and control wiring, restoring reliable power transfer and preventing loose or faulty connections. Ideal when wiring terminals are damaged, burnt, or corroded. What it does:

• Serves as the central connection point for incoming power and internal wiring harnesses.
• Replaces burned, melted, or loose terminal points that cause intermittent power or no-power symptoms.
• Stops arcing or overheating at damaged connection points, reducing risk of further wiring damage.
• Restores stable electrical contact for control boards and components that depend on the main power feed.

• One terminal board (single connection block as shown)

• Disconnect all power (unplug or shut off breaker) before beginning service.
• Photograph or label wiring to preserve correct connections before removal.
• Inspect adjacent wiring and connectors for heat damage; replace damaged items as needed.
• Tighten terminal screws securely but avoid over-torquing.

This control base assembly is the molded housing that holds the appliance's user-interface components. Replacing a damaged base restores proper alignment and secure mounting of the control board, switches, and display for dependable operation.

• Provides structural support and mounting points for the control board, switches, and display in the control area
• Keeps buttons/knobs aligned for smooth, consistent actuation
• Helps protect and organize wiring within the control panel
• Typical symptoms: cracked or broken housing, loose or sunken controls, buttons sticking or not lining up, rattling/vibration from the control area

• Disconnect power to the appliance before servicing
• Remove the control panel/console to access the base; retain screws and clips for reuse
• Transfer existing control components and wiring to the new base in the same positions
• Avoid overtightening screws into plastic; verify button travel and alignment before reassembly

This transformer supplies the low-voltage power needed by the appliance's control and ignition systems, restoring proper operation of electronic controls and spark ignition when the original transformer fails. What it does:

• Converts incoming mains power into the low-voltage output used by control boards and igniters
• Supports reliable spark generation for gas ignition systems on compatible appliances
• Helps restore responsive electronic controls and displays when a failed transformer causes loss of power
• Prevents intermittent control or ignition failures caused by a defective transformer

• One transformer

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Handle wiring harnesses and connectors carefully; ensure secure connections and proper routing

This control sheet is a thin insulating/ protective console panel that helps shield the appliance control assembly from heat, moisture, and debris for reliable keypad and electronics performance. It restores proper protection behind the control area. What it does:

• Provides a protective barrier behind the console to help prevent heat and moisture damage to control electronics
• Helps keep dust and debris away from the control board and keypad assembly
• Maintains the original spacing/insulation between the control and inner cabinet components
• Helps reduce the chance of shorts or corrosion caused by stray moisture

• One control sheet/console insulation panel

• Recommended for repair by someone comfortable working with appliance control panels
• Disconnect power (unplug or shut off breaker) before removing the console or accessing the control area
• Handle the control sheet gently to avoid tearing; reassemble fasteners in their original positions

This drive PWB supplies and regulates power to a driven component in your appliance, ensuring the motor receives the correct signals for smooth, reliable operation and restoring function when the original board fails.

• Provides regulated power and control signals to a motor or actuator
• Interfaces with the main control to manage operation
• On-board components help protect the circuit from faults
• Common symptoms of a failing board: motor won't run or is intermittent, only one speed works, erratic surging, or visible burn marks/clicking from the board area

• Disconnect power before servicing; verify no voltage is present
• Handle the board by the edges and avoid static discharge
• Photograph/document all connectors; transfer them one at a time
• Reinstall using original hardware; keep wiring clear of moving parts

A fan motor run capacitor that helps the appliance fan start and maintain smooth operation. Replacing a failed capacitor restores proper airflow and can help recover normal cooling performance when the original part wears out. What it does:

• Provides the phase shift and stored energy needed for the fan motor to start and run reliably.
• Common symptoms of a failing capacitor: fan not starting, fan humming or running intermittently, reduced airflow, or poor cooling performance.
• Used where a dedicated run capacitor is required for the appliance fan motor.
• Does not include installation tools or wiring harnesses.

• Disconnect power to the appliance before servicing to avoid electrical shock.
• Capacitors can hold a charge; discharge safely before touching terminals or disconnecting wires.
• Note terminal wiring positions (take a photo) to ensure correct reconnection.

This part is an air conditioner fuse. This is a genuine OEM part made by General Electric and has been sourced directly from the manufacturer. This part is intended to replace a faulty or blown fuse in multiple different models and brands of air conditioning units. Fuses are essential for preventing surges in power or high levels of current flow from reaching the appliance and damaging it. This part requires some knowledge of electrical circuits to replace. Ensure the air conditioning unit is completely disconnected from its power source before working on the appliance. Always make sure to take appropriate safety precautions when attempting any type of replacements. Proper tools are needed to install this part. For more accurate installation information on how and where to install this replacement fuse, refer to the original manufacturer diagrams or owner's manual. As an authentic replacement part, this fuse is suitable for use on various models of air conditioning units manufactured by General Electric and Hotpoint. Please note that this is a genuine part made of high-quality, non-corrosive, durable materials and is sold individually.

This fuse protects your appliance's electrical circuit from overcurrent. When the fuse opens, power to the controls or components is interrupted. Replace a blown fuse to restore protection and help prevent additional circuit damage.

• Opens the circuit during a short or surge to protect wiring and electronics
• Signs of a blown fuse: appliance dead/no power, display or controls unresponsive, interior lights out
• Typically fails due to shorted components, pinched wiring, or a power spike
• Tests open (no continuity) with a meter when failed

• Disconnect power at the breaker or unplug before servicing; some models contain capacitors that can retain a charge.
• Access the fuse, verify it is open with a continuity test, and note its placement.
• Replace only with the exact fuse type and rating specified for your model; never bypass or upsize a fuse.
• If a replacement fuse blows again, locate and correct the underlying short before restoring power.
