Parts for Bosch HDI7032U/06: Cooktop Asy Parts

This burner housing is the metal mounting and enclosure that secures a gas burner and its ignition components, restoring proper burner alignment and stable flame control for safe cooking. Use to replace worn, rusted, or damaged housings. What it does:

• Holds and positions the burner head, electrode/igniter, and associated fittings for correct ignition and flame shape
• Shields and directs gas flow around the burner for consistent combustion
• Prevents burner wobble and helps maintain safe clearances between the flame and appliance cabinet
• Commonly replaced when the housing is bent, corroded, cracked, or causing ignition/misfire issues

• One burner housing assembly

• Turn off gas supply and disconnect power to the appliance before beginning work
• Only attempt installation if you are comfortable with gas appliance repair
• Inspect and replace any worn gaskets, screws, or mounting hardware as needed; ensure proper alignment of the igniter/electrode
• After installation, check for gas leaks and verify correct ignition and flame behavior before normal use

This rubber seal provides a watertight barrier where installed, helping prevent leaks and maintain proper appliance performance. It replaces a worn or damaged seal to restore reliable sealing and reduce water damage risk. What it does:

• Creates a watertight seal at the mating surface to prevent leaks
• Helps maintain proper pressure/flow where the seal is used
• Commonly replaced when cracking, hardening, or visible wear appears
• Can stop intermittent leaking or water pooling near the appliance

• One rubber seal (single gasket as shown)

• Replace with the appliance powered off and water supply disconnected
• Clean mating surfaces before installing to ensure proper sealing
• Inspect surrounding components for damage while replacing the seal

The Burner Cap is an OEM part for Bosch Ranges. This part fits atop the burner assembly, playing a vital role in controlling and diffusing the flame for cooking.

A common issue with a malfunctioning or worn-out Burner Cap involves deterioration over time due to exposure to heat, grease, or cleaning agents. Damage or deformation to the cap can disrupt the flame pattern, leading to inefficient cooking or inconsistent heat distribution.

Symptoms of a defective Burner Cap may include:

• Uneven or erratic flames during burner operation
• Inadequate heat output or difficulties in achieving desired temperatures
• Visible signs of damage or wear on the burner cap's surface

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This burner housing secures the surface burner assembly on compatible gas cooktops and ranges, restoring proper burner alignment and stable flame performance. It replaces damaged or warped housings that cause burner wobble or inconsistent ignition. What it does

• Supports and positions the burner head and cap for correct flame pattern
• Aligns the igniter/electrode and maintains clearance from other components
• Helps prevent burner wobble, misalignment, and uneven heating
• Use when housing is cracked, corroded, bent, or otherwise damaged

• Shut off gas supply and power to the appliance before starting work
• Remove grates and burner caps to access the housing; keep track of fasteners
• Replace with the exact OEM part and secure fasteners without over-tightening

This rubber seal forms a watertight gasket used on the appliance to prevent leaks and keep internal compartments sealed during operation. It restores proper sealing to reduce visible water or drips and helps maintain cleaning performance. What it does:

• Creates a tight seal to prevent water from escaping the appliance during use
• Helps maintain correct internal water containment for effective operation
• Can reduce leaking, puddling, or moisture appearing around the appliance
• Restores the original sealing surface where worn, cracked, or compressed

• Inspect mating surfaces and remove debris before installing the new seal for a proper fit
• Press the seal fully into its channel or groove until seated evenly around the perimeter
• If adhesive or clips are used on the original part, reuse or replace them per the manufacturer's instructions
• Disconnect power and water (if applicable) before attempting replacement

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

This rubber grommet cushions and seals appliance components to reduce vibration, protect wiring or hoses, and help maintain a tight fit where parts pass through a panel or mounting point. It's a small but important wear item. What it does:

• Cushions vibrations and prevents metal-to-metal contact that can cause noise or wear
• Seals openings to help keep moisture, debris, and dust out of sensitive areas
• Protects hoses, wires, and tubing from chafing where they pass through panels
• Helps hold small components or fasteners in place at their mounting points

• Replace with the same size and shape grommet to ensure a proper fit and seal
• Inspect the surrounding area for wear or damage before installing
• Use basic hand tools; disconnect power and water before servicing
• If access requires disassembly, keep fasteners organized and follow OEM guidelines

This sealing ring creates a watertight seal in the dishwasher pump/motor area to help prevent leaks and protect the motor assembly. It's a small but essential replacement for worn or damaged seals. What it does:

• Seals pump housing joints to stop water leaks beneath the dishwasher
• Helps maintain proper water pressure and circulation for cleaning performance
• Prevents water from reaching the motor and electronics, reducing risk of damage
• Replaces brittle, cracked, or flattened seals that commonly cause under-unit leaks

• One sealing ring

• Turn off power and water to the appliance before starting any repair
• Inspect mating surfaces and clean away debris or buildup before installing the new ring
• Lubricate the seal lightly with OEM-recommended lubricant or a thin film of water if needed to ease installation
• If multiple seals or gaskets show wear, replace them together to ensure a complete seal.

This deflection unit redirects wash water to the upper area of the dishwasher to help maintain spray coverage and improve cleaning performance. It replaces a cracked, missing, or damaged deflector to restore proper water flow. What it does:

• Guides spray from the lower spray arm toward the upper rack for more even wash coverage
• Replaces a broken or warped deflector that can cause poor cleaning on upper-rack dishes
• Prevents water from being misdirected away from targeted wash zones
• Helps reduce splashing or unusual spray patterns caused by a damaged unit

• Typically snaps or screws into place; follow your model's service instructions
• Disconnect power and water supply before starting any dishwasher repairs
• Inspect surrounding clips and mounting points; replace any damaged hardware

This is a replacement mounting screw used to secure appliance panels and components. It restores proper fit and prevents rattling or loose parts so the appliance operates quietly and safely. What it does:

• Secures panels, brackets, or components to the appliance frame
• Prevents vibration-related noise and loose-fitting parts
• Replaces missing or damaged screws that can cause misalignment
• Helps maintain safe cabinet and component attachment during operation

• Use the matching screw hole and thread orientation; do not force if fit is not smooth
• Tighten until snug—avoid over-tightening to prevent stripping or damage
• Disconnect power and follow appliance-specific safety procedures before servicing
• Inspect surrounding fasteners and mounts for wear

This LP conversion kit provides the specific replacement jets needed to convert compatible gas ranges/ovens from natural gas to liquid propane, restoring correct burner orifice sizing for safe, efficient operation. What it does:

• Replaces factory burner jets/orifices with properly sized LP jets to achieve correct flame height and heat output
• Helps resolve low or uneven flames, burners that run poorly on propane, or ignition problems after conversion
• Used when converting a range/oven fuel type per manufacturer instructions
• Matches OEM fit and function when converting specified appliance models

• Follow the appliance manufacturer's LP conversion instructions and use the correct jets for your model
• Turn off gas supply and electrical power before beginning work
• After installation, perform a leak check and flame adjustment per OEM guidance
• Do not modify jets or attempt makeshift conversions; improper installation can cause unsafe operation
