Parts for Bosch NET9652UC/01: Cooktop Parts

This heating element heats dishwasher wash and rinse water and helps enable proper drying and sanitizing cycles. It restores the unit's ability to reach and maintain appropriate wash temperatures for cleaning performance. What it does:

• Warms wash and rinse water so detergents and sanitizing cycles work effectively
• Supports drying performance by raising internal temperature during final cycles
• Stops producing heat when the element is burned out, causing poor cleaning or no drying
• Can cause error codes or interrupted cycles if the element or its connections fail

• One heating element assembly

• Disconnect electrical power and water supply before servicing
• Handle the element and ceramic insulators carefully to avoid damage
• Verify correct fit and connection orientation for your model; secure wiring and seals

This heating element assembly provides the heating source for the appliance, restoring normal temperature output for drying/heating cycles. Replaces a worn or failed element to help recover proper operation and cycle performance. What it does

• Heats air or water as part of the appliance's main heating circuit.
• Restores normal cycle temperatures when the original element has failed.
• Can resolve symptoms such as no heat, extended cycle times, or temperature-related error codes.
• Works with the appliance's thermostat and safety cutouts to maintain safe operating temperature.

• Disconnect power (and gas supply, if applicable) before starting any repair.
• Handle with care to avoid damaging terminals, terminals insulation, or mounting brackets.
• Inspect surrounding wiring, connectors, and thermal cutouts; replace any damaged components.
• After installation, verify proper operation by running a test cycle and checking for correct heat and no unusual smells or noises.

This hi-light hotplate is a direct-replacement surface element for electric cooktops, restoring a single burner's heating surface so cookware heats evenly and cooking performance returns to normal. What it does:

• Replaces a damaged or cracked hi-light surface element used to produce radiant heat on the cooktop
• Restores proper heating when a burner is cool, intermittent, or not heating at all
• Provides an intact heat surface to prevent heat loss and reduce uneven cooking
• Matches the original element form and mounting style for a secure fit

• Disconnect power to the cooktop at the breaker before attempting service
• Handle the glass/ceramic surface carefully to avoid cracks or injury
• Basic tools may be required to remove the cooktop or retainers; follow the appliance service manual

A small chassis knockout protector that shields wiring and components where factory knockout holes are removed. Helps prevent wire abrasion and keeps openings tidy for safe appliance operation. What it does:

• Fits into a chassis knockout to protect wiring from sharp sheet-metal edges
• Helps prevent cable chafing and short circuits by covering exposed openings
• Keeps out debris while allowing routed harnesses to pass through the cabinet
• Commonly used where service or modifications require a sealed knockout

• One chassis knockout protector

• Install by pressing the protector into the knockout until it seats securely
• Ensure wiring is routed through the protector and not pinched between metal edges
• Disconnect power before servicing appliance to avoid shock or injury

Razor blade with cooktop cleaner

This fixing kit is replacement mounting hardware designed to secure appliance panels and trim for a tight, stable fit. Restores proper attachment to reduce rattling and loose or sagging parts for safer operation. What it does:

• Provides replacement screws, clips, and/or brackets used to fasten panels and trim
• Secures loose or vibrating panels to reduce noise and improve fit
• Replaces broken or missing fasteners that allow parts to shift or sag
• Helps restore proper alignment of exterior components after repair

• Disconnect power to the appliance before beginning any work
• Use the correct screwdrivers and hand tools to avoid damaging trim or finishes
• Handle metal edges and clips carefully to avoid cuts
• Test fit after installation

This cable harness routes power and signals between a major appliance control and its components so switches, sensors and motors can communicate and operate reliably. Replacing a damaged harness restores electrical continuity and component control. What it does

• Provides bundled wiring and connectors to link control boards with motors, valves, sensors and switches
• Replaces frayed, broken or burned wiring that can cause intermittent operation or complete failure of affected components
• Restores proper connector fit and secured electrical paths when original leads are loose or corroded
• Helps stop faults caused by shorted or open circuits when the harness is the damaged component

• Disconnect all power to the appliance before starting any repair.
• Compare the new harness to the old one for connector type, pin count and routing before installing.
• Route and secure wiring away from heat, sharp edges and moving parts; use original clips or ties when present.
