Parts for Ge JCS57F2WW: 02 - Cooktop Parts

This right-side hinge pin provides the pivot point that lets a refrigerator door open and close smoothly, restoring proper alignment and reducing sag or wobble for a secure seal. What it does:

• Acts as the pivot pin on the refrigerator door's right hinge assembly
• Supports door weight and keeps door aligned for an even seal
• Replace if the door sags, binds, makes noise, or no longer closes properly
• Works with existing hinge components; replaces worn, bent, or damaged pins

• Disconnect power and empty or support the door before removing hinge hardware
• Support the door while changing the pin to prevent injury or damage
• Tighten hinge fasteners to OEM torque and check door alignment after installation

This 6-inch surface element restores steady, even heat to the small burner on your electric range. Replace a burned-out coil to get back to reliable boiling, simmering, and everyday cooking performance.

• Converts electrical power into heat at the 6-inch burner position
• Helps when the small surface burner won't heat or heats unevenly
• Common signs include visible hot spots, blistering, or burned/loose terminals
• Seats in the drip bowl and connects to the proper surface element receptacle

• Disconnect power at the breaker or unplug the range; allow the element to cool before servicing
• Lift the old element from the drip bowl and pull straight out from the receptacle; avoid twisting or bending the coil
• Inspect the element receptacle for heat damage; replace the receptacle if contacts are burned or loose
• Fully seat the new element and ensure it sits level in the drip bowl before use

This 6-inch drip pan sits beneath a plug-in coil surface element to catch spills and reflect heat. Replacing a stained or warped pan refreshes the cooktop and helps the element seat properly. What it does:

• Installs under a 6-inch plug-in coil element to collect drips and boil-overs
• Reflects heat back to cookware for consistent heating
• Supports and aligns the element so it sits level in the cooktop
• Common signs to replace: heavy discoloration, rust, pitting, warping, or a burner that won't sit level

• 1 6-inch drip pan

• Disconnect power at the breaker and let all surface elements cool completely
• Lift the coil element straight out of its receptacle; remove the old pan
• Align the indexing notch and seat the new pan; firmly reinstall the element
• Verify the element is fully engaged and level before restoring power

This 8-inch surface burner element is the plug-in coil used on many electric ranges. Replacing a worn or failed element restores reliable heating and more even cooking performance on your stovetop.

• Provides heat to pots and pans when energized by the surface control
• Common fix for an element that won't heat or only heats partially
• Addresses visible coil damage such as breaks, blisters, or burned spots
• Corrects intermittent heating caused by an open or failing element

• Disconnect power to the range/unplug before servicing and ensure the element is cool
• Lift the old coil slightly, then pull straight out from the receptacle
• Inspect the receptacle/terminal block and drip bowl; replace if overheated or damaged
• Fully insert the new element terminals into the receptacle, seat the coil level, and test

This 8-inch surface burner drip pan sits beneath a plug-in coil element to catch spills and crumbs and support the element. Replacing a stained or warped pan helps keep the cooktop cleaner and ensures the burner sits level.

• Collects drips and debris under the 8-inch coil element
• Supports the element so it seats properly and sits level
• Refreshes the cooktop's appearance by replacing stained or rusted pans
• Common symptoms: burner wobbles, pan is warped/corroded, persistent baked-on residue

• Disconnect power and allow the cooktop to cool completely.
• Unplug the coil element from the receptacle and set it aside.
• Lift out the old pan; align the new pan with the opening and any locator tabs, then seat it flat.
• Reinstall the element, fully inserting the terminals and ensuring it rests correctly in the pan.
