Parts for Speed Queen LTZA7AWN2802: Cylinder Assy Parts

This bulkhead light assembly replaces the interior service light on commercial laundry machines, restoring illumination for easier loading and maintenance access. It's a direct-fit service kit designed for quick replacement. What it does:

• Replaces a burned-out or flickering bulkhead/service light
• Restores interior visibility for loading, unloading, and troubleshooting
• Replaces a cracked or damaged light housing or lens that lets moisture in
• Helps eliminate unexpected dark or dim compartment lighting

• Disconnect power to the machine before starting any work to avoid shock
• Remove access panels or bulkhead cover per the service manual to reach the light assembly
• Handle the lens and bulb carefully; ensure proper seating and secure fasteners

This is the rotating dryer cylinder assembly. Replacing a dented, rusted, or out-of-round cylinder restores smooth tumbling and helps prevent snags, noise, and uneven drying performance.

• Holds and tumbles laundry while working with the belt/drive system
• Internal white baffles lift and separate clothes for better airflow
• Smooth interior helps protect fabrics from catching or tearing
• Typical signs it's needed: loose or broken baffles, interior rust, dents, scraping/thumping once per revolution, or recurring fabric snags

• Disconnect power; for gas dryers, also shut off the gas supply
• Wear cut-resistant gloves—metal edges can be sharp
• Access typically requires removing the top/front panels and releasing belt tension; note belt routing
• Set drum, route belt correctly, spin by hand to confirm clearance, then reassemble and test
