Usually ships within 4 - 14 days
This part is discontinued by the manufacturer and is no longer available for purchase.
This clutch collar is an authentic OEM part sourced directly from the manufacturer for use in lawnmowers and lawn tractors. If there are problems with the lawnmower jerking and sputtering after changing gears, the clutch collar should be removed and replaced to keep the lawnmower running properly. The clutch collar is part of the clutch bearing. The clutch collar is used between bevel gears as spacers and allows them to move in sync with the pinion gear. If the clutch collar is deteriorated, broken, or missing, a new one should be installed.Make sure the lawnmower is on a flat surface. Remove the spark plug and disconnect the battery. A screwdriver, pliers, socket set, wrench set, and nut driver are required to make this repair. Take the transmission out of the lawnmower. Open the case on the transmission and remove the broken clutch collar. Install the new clutch collar. Reverse the process to reassemble the lawnmower. This clutch collar is a high tensile metal part that is sold individually. It is designed for use in lawn tractors manufactured by Craftsman.
Lawn tractor detent shaft assembly fixes gear shifting problems and loose transmission engagement. Direct replacement part for precise shift control.
Hex screw fastener for lawn tractors and outdoor power equipment. Secures components throughout the machine. Replace if stripped, overtightened, or missing.
This ball detent is a genuine MTD replacement part for appliances operated by small engines, including lawn tractors, lawn mowers, snowblowers, leaf blowers, chipper shredders, and tillers. The function of a ball detent is to temporarily keep two parts in place relative to one another, as one or both of the parts rotate.A ball detent might have to be replaced in the event that it suffers damage over time or is lost or misplaced. It is possible for ball detents to fall out of their spot, meaning that the parts that it ordinarily holds in place will not be able to rotate properly. Additionally, a ball detent might have to be replaced if there is material deterioration. If this occurs, a replacement ball detent part should be ordered and secured to the small engine appliance immediately. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. This ball detent is compatible with the following brands: MTD, Yard Man, Yard Machines, and Troy-Bilt.
Fixes weak or no braking on lawn tractors and riding mowers. This brake disc restores stopping power when brakes drag, squeal, or fail to engage properly.
This replacement part is an input shaft for lawnmowers. The input shaft transfers torque from the clutch disk to the countershaft allowing for the lawnmower to switch gears. If the mower is no longer shifting properly, the input shaft might need to be replaced. Luckily replacing an input shaft is a relatively simple process.Before beginning, make sure that the mower engine has cooled. Open the hood cover, and locate the gearbox. Remove the mounting screws that attach the gearbox to the mower. Once removed, remove the gearbox and locate the damaged input shaft. Using a pipe wrench remove the old shaft by rotating it till it comes undone. Once removed, rethread the new input shaft into its proper position. Reattach the gearbox to the mower. After replacing, make sure to power the mower to see if the gears switch properly.This genuine OEM part is sold individually and is compatible with MTD brand lawnmowers.
Lawn tractor input pinion gear that transfers power to drive components. Metal gear that wears over time causing loss of forward motion or grinding noise.
