Parts for Ge ZDP366LP4SS: 06 - Door Assembly Parts

This small set screw secures components inside your refrigerator. Replacing a missing or stripped set screw restores a tight, reliable hold so attached parts stay aligned and are less likely to loosen or rattle during use.

• Fastens an attached part to its mounting point to prevent movement or slipping
• Helps maintain proper alignment of handles, brackets, or trim pieces
• Reduces wobble, vibration, and rattling noises caused by loose hardware
• Replaces missing, stripped, or corroded set screws

• Unplug the refrigerator and shut off water if working near door/dispenser areas
• Support the part being secured; start the screw by hand to avoid cross-threading
• Tighten with the correct driver for your model; do not overtighten to prevent stripping
• The component is secure and aligned before restoring power

This small end cap fits the end of an extension piece to act as a stop and finish. It restores a secure, finished edge so the sliding component or trim stays aligned and doesn't over-travel during use.

• Caps the end of an extension rail or trim to prevent over-travel and pullout
• Keeps the assembly aligned to reduce wobble
• Replaces cracked, missing, or worn caps
• Helps eliminate rattling and exposed edges

• Disconnect power and allow all hot surfaces to cool before servicing
• Access the end of the extension/rail; release any locking tab and remove the old cap
• Align and snap or press the new cap into place
• Verify smooth travel and a secure stop after installation

This mounting screw secures appliance components to the chassis for a tight, rattle-free fit. Replacing a missing, stripped, or corroded fastener helps keep panels, brackets, or burner assemblies properly aligned and secure.

• Fastens designated parts to the appliance frame or mounting points
• Helps maintain proper alignment of panels, trim, brackets, or burner assemblies
• Restores hold when the original screw is worn, rusted, or lost
• Symptoms include loose or wobbly components, rattling/vibration, or visible gaps

• Disconnect power; allow all surfaces to cool. For gas units, also shut off the gas supply.
• Use the correct driver/bit; avoid cross-threading.
• If mating threads or clip/nut are damaged, repair or replace them before installing.
• Tighten until secure; do not overtighten to prevent stripping.

This 27" glass oven door provides the visible, heat-resistant window for an oven cavity so you can monitor cooking while keeping heat contained. Durable replacement glass restores a secure, clean-looking door surface. What it does:

• Replaces damaged, cracked, or chipped oven door glass to restore safe viewing
• Helps maintain oven temperature by sealing the door opening
• Prevents food splatter from contacting internal components
• Restores proper visibility for checking progress without opening the door

• One 27" oven glass door

• Disconnect power to the appliance and allow the oven to fully cool before starting
• Handle the glass with gloves and place on a protected, padded surface to avoid damage
• Some door removal or hinge access is typically required; keep track of fasteners and brackets

This right-side refrigerator door hinge replaces a worn or damaged hinge to restore correct door alignment and smooth opening. It's a direct-fit hinge used where the door is sagging, binding, or not sealing properly. What it does:

• Supports the right-hand door and provides a pivot point for opening and closing
• Restores proper door alignment to improve sealing and temperature consistency
• Reduces binding, scraping or noisy operation caused by a bent or worn hinge
• Helps prevent accelerated wear to the door and cabinet mounting surfaces

• Disconnect power to the appliance and remove stored items from the door before starting.
• Support the door while removing and installing the hinge to prevent damage or injury.
• Use the correct hand tools and tighten fasteners to the manufacturer's torque recommendations.
• If alignment issues persist after installation, check hinge placement and door stops per service instructions.

This left-side refrigerator door hinge secures and guides the door on compatible GE refrigerators, helping the door open and close smoothly and maintain proper alignment. Replacement hinge restores stable door movement and sealing. What it does:

• Provides a reinforced pivot point so the door swings freely without sagging
• Keeps the door aligned to preserve gasket contact and cooling performance
• Replaces worn or bent hinges that cause uneven gaps or noisy operation
• Works as part of the door mounting system to support normal door weight

• One left-side door hinge

• Disconnect power to the appliance and remove stored items from the door before starting
• Support the door while removing hinge fasteners to prevent dropping or damage
• Retain original screws and hardware unless the replacement explicitly includes them

This inner oven door glass replaces a cracked or cloudy panel to restore a clear view into the oven cavity and help the door seal properly. It fits into the oven door assembly and restores safe, functional operation. What it does:

• Replaces damaged, cracked, or discolored inner oven door glass
• Restores visibility so you can monitor cooking without opening the door
• Helps maintain the oven door seal and proper heat containment
• Prevents loose glass fragments that could fall into the oven cavity

• High-level replacement: typically accessed by removing the outer door panel; follow the oven model's service manual
• Handle glass carefully; wear cut-resistant gloves and eye protection
• Disconnect power and allow the oven to cool fully before starting work
• If clips, brackets, or adhesive are required, obtain the specific hardware for your door variant

This replacement screw fastens appliance components to restore secure fit and reduce vibration or panel movement. Simple, direct replacement for a missing or stripped fastener to help maintain proper assembly and operation. What it does:

• Secures panels, brackets or trim to keep parts aligned and prevent rattling
• Restores mounting where a lost or damaged screw causes loose or sagging components
• Helps maintain electrical and mechanical connections by keeping parts properly seated
• Small hardware solution for cosmetic and functional stability

• Use the correct sized screwdriver or driver bit to avoid stripping the head
• Inspect mating threads and replace if damaged; do not force a stripped screw
• Tighten until snug — avoid over-tightening which can crack plastic or strip threads
• If accessing areas near power or controls, disconnect appliance power first and follow all safety precautions

This replacement screw secures appliance components so panels, brackets, and trim stay tight and aligned. Use it to replace a missing, stripped, or rusted fastener and restore a solid, rattle-free fit in the affected assembly.

• Fastens parts to the chassis/frame or mounting brackets
• Replaces lost, damaged, or corroded hardware
• Can help address loose or vibrating panels and minor misalignment
• Maintains a secure attachment during normal operation

• Disconnect power before servicing; for gas appliances, also shut off the gas supply
• Match the screw to the original location and reuse any clips or washers if present
• Start threading by hand to avoid cross-threading; tighten snugly without overtightening
• Repair/replace damaged receiving threads or clip for proper hold

This 27" oven door gasket seals the gap between the door and oven body to help maintain proper cavity temperature and reduce heat loss during cooking. It restores a tighter door seal for more consistent baking and roasting. What it does:

• Replaces worn or torn door seal that lets oven heat escape
• Helps the oven reach and maintain set temperatures more reliably
• Reduces hot spots and uneven cooking caused by a failing seal
• Minimizes heat transfer to surrounding cabinetry and reduces energy loss

• One door gasket (27")

• Disconnect power and allow the appliance to cool completely before starting
• Remove the old gasket and any adhesive or fasteners before installing the new gasket
• Press the new gasket into the door channel evenly, ensuring proper orientation and a continuous seal

This is a 1/4-20 x 3/4 inch hex washer head screw used to fasten appliance components securely. It provides a durable, low-profile fastening point to keep panels and assemblies aligned and stable. What it does:

• Secures panels, brackets, and assemblies to prevent movement and maintain alignment
• Helps stop rattling or vibration caused by loose fasteners
• Restores proper fit where a missing or damaged screw causes gaps or instability
• Works with metal-to-metal fastening points requiring 1/4-20 thread engagement

• Disconnect power to the appliance before starting any repair
• Start threads by hand to avoid cross-threading, then tighten with the appropriate hex driver or socket
• Do not overtighten; snug until secure to avoid stripping threads or damaging parts
